Innovation of the Experimental Facility for the Study of Flutter in the Institute of Thermomechanics AS CR and Some Results Obtained from Initial Experiments

Abstract:

Experimental facility situated in the test section of the wind tunnel suction type was adjusted both in the total construction and in the construction of the fluttering body, the methodology of the measurement and evaluation of the flow and dynamic parameters during flutter were also changed. Preserved was the conception of the NACA0015 profile with two degrees of freedom, rotational and translational. Torque elasticity was now realized by the coil spring and changed by different length of this spring or by different diameter of the spring wire. The pitch angle of the profile was now measured by the magnetic rotary encoder. The translational position was indicated by the magnetic linear encoder and was centered by plane springs situated on both ends of the shiftable frame. With this model the testing measurement was realized by its self-excited vibration of flutter type in the range of Mach numbers M=0.20-0.215 and Reynolds numbers 263 000 – 283 000. Results obtained with M=0.21 and Re=276 000 are presented.

• Periodical: Applied Mechanics and Materials (Volume 821)
• Pages: 144-151
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.821.144
• Online since: January 2016
• Authors: V. Vlček, M. Štěpán, Igor Zolotarev*, Jan Kozánek
• Keywords: Aeroelasticity, Flutter, Interferometry, Subsonic Flow

References

[1] V. Vlček, J. Kozánek: Preliminary interferometry measurements of a flow field around fluttering NACA0015 profile. Acta Technica, 2011, Vol. 56, l No. 4., pp.379-387.

[2] I. Zolotarev, V. Vlček, J. Kozánek: Experimental results of a fluttering profile in the wind tunnel. Flow-Induced Vibration. Dublin, School of Engineering Trinity College, Dublin, 2012, (eds. Meskell, C., Bennett, G. ), pp.677-680.

[3] M. Štěpán: Measurement of pitch on a fluttering profile (in Czech), DYMAMESI 2014 - Proceedings, Prague, November 25-26, 2014, pp.67-72.

[4] J. He, Z. F. Fu: Modal Analysis, Oxford, Butterworth-Heinemann, (2004).

[5] J. Kozanek, V. Vlcek, I. Zolotarev: The Flow Field acting on the Fluttering Profile, Kinematics, Forces and Total Moment, Int. J. Str. Stab. Dyn., Vol. 13, No 7, 2013, 1340009, 7 p.

DOI: 10.1142/s0219455413400099

[6] J. Kozánek, V. Bula, I. Zolotarev: Mathematical model of the support of experimental aerodynamical profile (in Czech), Interaction and Feedbacks 2010 - Proceedings. Prague 2010, pp.57-64.
