Mono-Objective Optimization of a Photovoltaic Tracking System with LPF Controllers

Abstract:

The work deals with the optimal design of a single-axis solar tracker, which is used to adjust the daily position of a photovoltaic system in order to capture as much as possible solar radiation. The two main components of the solar tracker (the mechanical device and the control system) have been coupled (integrated) in the concurrent engineering concept. For assuring high stability and robustness, the control system is a cascaded two-loop employing LPF (Low-Pass Filter) controllers. The controlled parameter in the main (external) loop is the daily angle of the photovoltaic platform, while in the secondary (internal) loop the linear velocity in the driving actuator is monitored. The mono-objective optimization problem is described in the following way: to minimize the difference between the imposed and current daily angle (thus preserving a high energetic efficiency of the tracking system), considering the controllers’ gains as independent design parameters.

• Periodical: Applied Mechanics and Materials (Volume 823)
• Pages: 7-12
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.823.7
• Online since: January 2016
• Authors: Cătălin Alexandru*
• Keywords: Design for Control, Efficiency, Low-Pass Filter, Pv System, Tracking Mechanism

References

[1] E. Calabrò, Determining optimum tilt angles of photovoltaic panels at typical north-tropical latitudes, Journal of Renewable and Sustainable Energy Vol. 1 (2009) 033104.

DOI: 10.1063/1.3148272

[2] S. Yilmaz, H.R. Ozcalik, F. Dincer, The analysis on the impact of the roof angle on electricity energy generation of photovoltaic panels in Kahramanmaras, Turkey - A case study for all seasons, Journal of Renewable and Sustainable Energy Vol. 7 (2015).

DOI: 10.1063/1.4919085

[3] C. Alexandru, M. Comşiţ, The energy balance of the photovoltaic tracking systems using virtual prototyping platform, IEEE International Conference on the European Electricity Market (2008) 253-258.

DOI: 10.1109/eem.2008.4579038

[4] C. Alexandru, C. Pozna, Virtual prototype of a dual-axis tracking system used for photovoltaic panels, IEEE International Symposium on Industrial Electronics (2008) 1598-1603.

DOI: 10.1109/isie.2008.4676923

[5] C. Alexandru, The design and optimization of a photovoltaic tracking mechanism, IEEE International Conference on Power Engineering, Energy and Electrical Drives (2009) 436-441.

DOI: 10.1109/powereng.2009.4915246

[6] C. Alexandru, A novel open-loop tracking strategy for photovoltaic systems, Scientific World Journal 2013 (2013) 205396(1-12).

DOI: 10.1155/2013/205396

[7] S.M. Çinar, F.O. Hocaoğlu, M. Orhun, A remotely accessible solar tracker system design, Journal of Renewable and Sustainable Energy 6 (2014) 033143(1-12).

DOI: 10.1063/1.4885099

[8] T. Elakkiy, A. Nandhini, Comparative survey on various solar battery systems and tracking mechanisms, International Journal of Applied Engineering Research 10 (2015) 4141-4154.

[9] C. Alexandru, I.N. Tatu, Optimal design of the solar tracker used for a photovoltaic string, Journal of Renewable and Sustainable Energy 5 (2013), 023133 (1-16).

DOI: 10.1063/1.4801452

[10] M.A. Ioniţă, C. Alexandru, Optimal design of the mechanical device for a photovoltaic tracking mechanism, Applied Mechanics and Materials 186 (2012) 114-123.

DOI: 10.4028/www.scientific.net/amm.186.114

[11] I. Barbu, Virtual prototyping tools applied in mechanical engineering, Mecatronica 3 (2004) 9-12.

[12] A. Georgescu, P.A. Simionescu, I. Tălpăşanu, Design and prototyping of a cost-effective sun tracking system for photovoltaic panels, ASME International Mechanical Engineering Congress and Exposition 6B (2015) V06BT07A035(1-5).

DOI: 10.1115/imece2014-37682

[13] K. Maharaja, R.J. Xavier, L.J. Amla, P.P. Balaji, Intensity based dual axis solar tracking system, International Journal of Applied Engineering Research 10 (2015) 19457-19465.

[14] S.A. Sharaf Eldin, M.S. Abd-Elhady, H.A. Kandil, Feasibility of solar tracking systems for PV panels in hot and cold regions, Renewable Energy 85 (2016) 228-233.

DOI: 10.1016/j.renene.2015.06.051

[15] I. Barbu, Phenomena occurring in achieving integrated circuit boards using ultraviolet light, Annals of the Oradea University, Fascicle of Management and Technological Engineering XIII (2014) 303-306.

DOI: 10.15660/auofmte.2014-1.2954
