Inspection on Buckling Mode of Crossed-Rib Reinforced Composite Laminates Panel by Fringe Projection Profilometry

Abstract:

Digital fringe projection profilometry (FPP) is suitable to inspect surface profile of object, with some apparent advantages of non-contact, full-field measurement, simple apparatus, high precision, and real-time profile automation. Four phase-shifted sinusoidal fringe patterns are circularly projected onto the surface of a composite laminates panel reinforced with crossed ribs. Phase shifting method is applied to inspect the surface profile variations during compression. The profile results reveal that different local buckling modes appear at different crossed ribs, where the wave villages locate at the middle and the wave peaks occur at the composite panel ends. From the details of the deflection analysis, it can be seen that the local buckling modes couple with the whole bending of the composite panel. The local buckling modes vary with the applied load and the experimental results are helpful to understand its failure mechanism.

• Periodical: Applied Mechanics and Materials (Volume 83)
• Pages: 168-173
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.83.168
• Online since: July 2011
• Authors: Zhen Kun Lei, L. C. Zhan, R. X. Bai, F. J. Yang
• Keywords: Buckling Mode, Crossed-Rib Reinforced Composite, Fringe Projection Profilometry, Phase Analysis

References

[1] Freeman W. T., The use of composites in aircraft primary structure, Composites Engineering, 3(7-8): 767-775 (1993).

DOI: 10.1016/0961-9526(93)90095-2

[2] Immarigeon J-P., Holt R. T., Koul A. K., Zhao L., Wallace W., Beddoes J. C., Light weight materials for aircraft applications, Materials Characterization, 35(1): 41-67 (1995).

DOI: 10.1016/1044-5803(95)00066-6

[3] Hosseini-Toudeshky H., Loughlan J., Kharazi M., The buckling characteristics of some integrally formed bead stiffened composite panels, Thin-Walled Structures, 43(4): 629-645 (2005).

DOI: 10.1016/j.tws.2004.08.007

[4] Wodesenbet E., Kidane S., Pang S. S., Optimization for buckling loads of grid stiffened composite panels, Composite Structures, 60(2): 159-169 (2003).

DOI: 10.1016/s0263-8223(02)00315-x

[5] Takeda S., Aoki Y., Ishikawa T., Takeda N., Kikukawa H,. Structural health monitoring of composite wing structure during durability test, Composite Structures, 79(1): 133-139 (2007).

DOI: 10.1016/j.compstruct.2005.11.057

[6] Ryu C. Y., Lee J. R., Kim C. G., Hong C. S., Buckling behavior monitoring of a composite wing box using multiplexed and multi-channeled built-in fiber Bragg grating strain sensors, NDT & E International, 41(7): 534-543 (2008).

DOI: 10.1016/j.ndteint.2008.05.001

[7] Hu E. R., He Y. M., Wu W. P., Further study of the phase-recovering algorithm for saturated fringe patterns with a larger saturation coefficient in the projection grating phase-shifting profilometry, Optik, 121(14): 1290-1294 (2010).

DOI: 10.1016/j.ijleo.2009.01.007

[8] Salvi J., Fernandez S., Pribanic T., Llado X., A state of the art in structured light patterns for surface profilometry, Pattern Recognition, 43(8): 2666-2680 (2010).

DOI: 10.1016/j.patcog.2010.03.004

[9] Zhang S., Recent progresses on real-time 3D shape measurement using digital fringe projection techniques, Optics and Lasers in Engineering, 48(2): 149-158 (2010).

DOI: 10.1016/j.optlaseng.2009.03.008

[10] Su X. Y., Zhang Q. C., Dynamic 3-D shape measurement method: A review, Optics and Lasers in Engineering, 48(2): 191-204 (2010).

DOI: 10.1016/j.optlaseng.2009.03.012
