Investigation of Coating Liquid Layer Behaviour at Curved Solid Edges

Abstract:

In our study we examined the behaviour of thin liquid layers at curved solid edges experimentally and numerically by coating investigations based on the laser-induced fluorescence technique (LIF) and by numerical film simulations based on the Volume-of-Fluid multiphase flow model (VOF), respectively. The main motivation was to find optimal combinations of influencing quantities to reduce the so-called Fat-Edge effect. Therefore, we performed a study of these influencing quantities, in which application parameters like edge curvature radii of the solid substrates and application layer thicknesses as well as determining liquid properties like viscosity and surface tension have been varied. Results are described qualitatively at corresponding Fat-Edge shapes and quantified by suitable Fat-Edge parameters, which had to be identified and selected.We can show that adverse and appropriate influencing parameter combinations exist, which generate conspicuous and less distinctive Fat-Edges, respectively. The experimental findings and proportionalities regarding Fat-Edge shapes and dimensions are found to be physically plausible. Furthermore, an order of significance of the influencing quantities has been established.Eventually, we could derive a dimensionless quantity by dimensional analysis, which describes the Fat-Edge effect. Thus, the Fat-Edge effect may also be described by the application of similarity theory and a corresponding dimensionless number.

• Periodical: Applied Mechanics and Materials (Volume 831)
• Pages: 126-143
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.831.126
• Online since: April 2016
• Authors: Oliver Sommer*, Günter Wozniak
• Keywords: Dimensional Analysis, Fat-Edge Effect, LIF Coating Investigation, Thin Liquid Layer, VOF Thin Film Simulation

References

[1] Meichsner, G.; Mezger, T. G.; Schröder, J.: Lackeigenschaften messen und steuern, Vincentz Network, Hannover, (2003).

DOI: 10.1515/9783748600190

[2] Mischke, P.: Filmbildung, Vincentz Network, Hannover, (2007).

[3] Palitschka, F.; Storace, E.; Tönnies, D.: Standard AZ4999 Spray Coating Process for Conformal Coating Across KOH Etched Wafers, SÜSS MicroTec Lithography GmbH - Application Center, Application Note #06. 2013, (2013).

[4] Storace, E.; Kaneko K.; McCrone, T.; Tönnies, D.: Conformal Deposition of Novolak Resist onto KOH Etched Structures by Spray Coating, SÜSS MicroTec Lithography GmbH – Application Center, Application Note #01. 2013, (2013).

[5] Zorll, U.: Einflussgrößen bei der Formgestaltung von Lackoberflächen, Jahrbuch Oberflächentechnik, Band 40, 1983, 361-371.

[6] Sommer, O.; Moller, D.; Wozniak, G.: Experimental and numerical investigation of thin liquid layers at curved solid edges, Key Engineering Materials Vol. 597: Progress in Mechanical Engineering and Technology, 51-62, (2013).

DOI: 10.4028/www.scientific.net/kem.597.51

[7] Sommer, O.; Wozniak, G.: On the behaviour of thin liquid layers at curved solid edges, Proc. Appl. Math. Mech. Vol. 14, 683–684, (2014).

DOI: 10.1002/pamm.201410325

[8] Sommer, O.: Ein Beitrag zur Untersuchung des Verhaltens dünner Flüssigkeitsfilme nahe gekrümmten Substratoberflächen, Dissertation, Technische Universität Chemnitz, Germany, (2014).
