Flexible and Ergonomically Three Wheel Bike for Post Stroke Patient

Abstract:

This paper explains the new design of the three wheel bike for post-stroke patients as a equipment for physical therapy. The bike can be pedaled by foot and / or by hand simultaneously. Bike frame is made of aluminum alloy pipe and consists of front and rear frame. The front frame is equipped with a steering system that can regulate the moving of two wheels of diameter of 22 ". The rear frame is equipped with a fold mechanism, shock breaker, seat and chain stay pipes for clamping the rear wheel with diameter of 22 ". The rear frame is also equipped with a mechanism of transfer speed in three levels. Bike length is 1645 mm, width 615 mm and height 1035 mm. However, after folded the bike dimension became 725 mm long, 460 mm wide and 1035 mm high. By using CATIA software the strength frame material is simulated and analyzed. The bike design is evaluated from ergonomics aspect with RULA method. The proposed design is performed into a prototype. The prototype test is conducted. The result test show, that the bike is pedaled, either by hand or foot, strong, safe and comfortable to ride. In order to evaluate the design benefit, the pedal test is also conducted in various pedal velocities by 3 post stroke patients as respondent. During 6 minutes pedaling number of rider heartbeat is measured. The result shows all the number of heartbeat is not exceeded than 120 HR. That means the bike is enough light to pedal or the patient must not give extra power to ride the bike. Moreover, during 4 weeks therapy by cycling the bike, pedal velocity each respondents is increase significantly around 26-96%, this means the muscle contraction of respondents is reduce and developed bike can be used as alternative equipment for physical therapy of post stroke patient. Because light and foldable, the bike can be moved easily and put in the trunk of a car without problem.

• Periodical: Applied Mechanics and Materials (Volume 836)
• Pages: 14-19
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.836.14
• Online since: June 2016
• Authors: I Made Londen Batan, Syifa Syifa, Danny Prasetyo
• Keywords: Ergonomic, Flexible, Heartbeat, Post Stroke, Three Wheel Bike

References

[1] L. Nelson, J. Carlsson, A. Danielsson, A. Fugi-Meyer, K. Hellstrom, L. Kristensen, B. Sjoulund, K.S. Sunnerhagen, G. Grimby, Walking training of patients with hemiparises at an early stage after stroke: a comparison of walking training on a treadmill with body weight support and walking training on ground, Clinical Rahabilitation, Vol 15 (2001).

DOI: 10.1191/026921501680425234

[2] F. M., Ivey, C. E. Hafer-Macko, R.E. Macko, Exercise Rehabilitation After Stroke, NeuroRX – The Journal of American Society for Experimental NeuroTherapeuitics, Vol 3, No. 4 (2006), pp.439-450.

DOI: 10.1016/j.nurx.2006.07.011

[3] I.T. da C. Filho, Peter. H. Limb, H. Cureshy, H. Henson, T. Monga, E.J. Protas, A Comparison of Regular Rehabilitation and Regular Rehabilitation with Supported Treadmill Ambulation Training for Acute Stroke Patients, Journal of Rehabilitation and Research Development, Vol. 38, No. 2, March/April 2001, pages 245-255.

DOI: 10.1053/apmr.2002.34267

[4] H. Khuram, Effect on Aerobich Physically Traininig on Stroke Supervisors, Umea International School of Public Health, Dept. of Public Health and Clinical Medicine, Umea University, (2011).

DOI: 10.26911/theicph.2016.022

[5] I M. L. Batan, Rodika, Riva'i, Three Wheel Bike as Physical Therapy for Post Stroke Patient, Applied Mehanics and Materials, Trans Tech Publication, Swtizerland, Volume 776 (2015), pp.337-342.

DOI: 10.4028/www.scientific.net/amm.776.337

[6] R. J. Ingebretsen, The Physics of the Human Body, in: Michael Doleae, Chapter 3 - Muscle and Force, Rotator Cuff and Shoulder Impingement Syndrome, Companion Manual Physics 3110, Autumn Semester 2002, pp.4-5.

[7] McAtamney, Lynn and Corlett, E. Nigel, (1993), RULA: A Survey Method for Investigation of Work-related Upper Limb Disorders, Applied Ergonomics, vol. 24 No. 2, pp.91-99.

DOI: 10.1016/0003-6870(93)90080-s

[8] Bompa, Stroke Prevention Exercise Program (SPEP) Target Heart Rate Zone, University of Wisconsin Hospital, Madison, (1999).

[9] I M. L. Batan, D. Harnany, E. Rinaldi. The Effect Seat Tube Angle (STA) on Muscle Tension Leg Riders. Advanced Material Research, Trans Tech Publication, Switzerland Vol. 939 (2014), pp.592-599.

DOI: 10.4028/www.scientific.net/amr.939.592
