Experimental Study of the Cross Flow Turbine

Abstract:

The experimental study was intended to investigate characteristics of the cross flow turbine based to the three models designed on the same runner diameter with different runner length of each. The Flow rates were measured by magnetic flow meter, the forces were detected by using spring balance and turbine speeds were detected by tachometer. The performance characteristics are shown by the relation of Power and efficiency versus jet entry arc, as well as the relation of Power and efficiency versus ratio between diameter and width of runner. The study indicated that the efficiency of the models were slightly difference, the highest efficiency indicated by the turbine with the ratio between length of runner and the diameter of the runner was 2; It was corresponding to the 75 degree entry arc.

• Periodical: Applied Mechanics and Materials (Volume 836)
• Pages: 304-307
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.836.304
• Online since: June 2016
• Authors: Djoko Sutikno*, Rudy Soenoko, Sudjito Soeparman, Slamet Wahyudi
• Keywords: Cross Flow Turbine, Diameter Ratio, Length Ratio, Micro Scale Hydropower, Performance Characteristic

References

[1] Aziz and Desai An Experimental Study of the Effect of Some Design Parameters on Cross flow Turbine Efficiency , J. Energy Eng. 1994. 120: 17-34.

[2] Djoko Sutikno, Experimental Study of the Cross flow Turbine, Masters Thesis University of Technology Sydney; Sydney, 1990, 177.

[3] Djoko Sutikno, "The effects of Runner blade Wide as a Function of Nozzle Entry Arc to Performance Characteristics of the Crossflow Turbine) Preliminary Dissertation University of Brawijaya; Malng, Indonesia.

[4] Fiuzat and Akerkar The Use of Interior Guide Tube in Crossflow Turbine , J. Energy Eng. 1991. 117: 57-70.

[5] Hothersall, R., Review of the Cross flow Turbine, GEC Energy Systems Limited, Cambridge Road, Whetstone, Leiscester LE 3LH, UK, 10.

[6] Kosrowpanah, S. ; Albertson, M.L.; Fiuzat, A.A., Historical Overview of Crossflow Turbine, International Water Power & Dam Constaction, October 1984, pp.38-43.

[7] Nakase, Y.; Fukutomi; Watanabe,J., A Study of Crossflow Turbine, Effects of Nozzle Shape on its Performance., From Small Hrydro-Power Fluid Machinery, Presented at the Annual Winter Meeting, ASME, Phoenix, Arizona, November 14-19, 1982, ASME, New York, pp.129-133.

[8] Olgun Investigation of the Performance of a Crossflow Turbine ,J. Energy Res., 22, 953Ð964 (1998).

[9] Ott dan Chappell Design and Efficiency Testing of a Crossflow Turbine, (1989).

[10] Varga, J., Test with the Banki Water Turbine., Acta Technica Academicae Scientiarum Hungaricae, 27(1959), No. ½, pp.57-64.
