Collision-Free Trajectory Generation for Waterway Surfaces of a PDC Drill Bit

Abstract:

After describing geometric characteristics of a PDC drill bit’s waterway surfaces, an approach for collision-free trajectory generation are proposed. The trajectory is planned by an iso-parametric method firstly, while the tool orientations are determined by visibility cones, which are the bounded regions between the opposite surfaces of neighboring blade wing pairs. Tool orientations are produced by calculations of critical points and interpolations between them. Furthermore, the criterion of whether tool orientations pass through the constraint surface and the linear interpolation formula of tool orientations are given. The research has created conditions for the success machining of PDC drill bits, and related machining enterprises of impellers and propellers will also be benefited.

You might also be interested in these eBooks

Green Power, Materials and Manufacturing Technology and Applications

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 84-85)

Pages:

194-198

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.84-85.194

Citation:

Cite this paper

Online since:

August 2011

Authors:

Xu Bing Chen, Yang Song, Han Xin Chen

Keywords:

Collision-Free Trajectory, Iso-Parametric Method, Visibility Cone, Waterway Surface

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Y. Zhang, Z. Zhang, et al. CAD/CAM technique in PDC drilling bits female mould processing base on Pro/E. Oil Field Equipment. Vol. 34, No. 5, p.34 (5): 23-27 (2005).

Google Scholar

[2] J. Liu, J. Xu. Computer-aided design of PDC bit placing cutting. Coal Geology & Exploration. Vol. 31, No. 3, pp.62-64 (2003).

Google Scholar

[3] A. Lasemi, D. Xue, P. Gu. Recent development in CNC machining of freeform surfaces: A state-of-the-art review. Computer-Aided Design. Vol. 42, No. 7, p.641–654 (2010).

DOI: 10.1016/j.cad.2010.04.002

Google Scholar

[4] B. Ren, Y. Tang. Geometry modeling theories and their applications in NC machining. Harbin: Harbin Institute of Technology Press. p.106–107 (2000).

Google Scholar

[5] Sun J. Computer Graphics. Version 3. Beijing: Tsinghua University Press. p.349–350 (1998).

Google Scholar

[6] C. Jun, K. Cha, Y. Lee. Optimizing tool orientations for 5-axis machining by configuration-space search method. Computer-Aided Design. Vol. 35, No. 6, pp.549-566 (2003).

DOI: 10.1016/s0010-4485(02)00077-5

Google Scholar

[7] Z. Yin, H. Ding, Y. Xiong. Accessibility analysis algorithm and application based on visibility cone. Science in China Series E. Vol. 33, No. 11, pp.979-988 (2003).

Google Scholar

[8] M. Luo, B. Wu, et al. Five-axis tool orientation optimization based on kinematical method. Journal of Mechanical Engineering. Vol. 45, No. 9, pp.158-163 (2009).

DOI: 10.3901/jme.2009.09.158

Google Scholar
