Modeling of Wing Flapping Motion

Abstract:

In flying animal world, there are different flapping motions to produce lift and thrust depending on their species and size. Recent development in Unmanned Aerial Vehicle had tried to mimic flying animal. Rather than having two separate systems in providing lift and thrust, the wing upstroke and downstroke movement combined with wing twisting produce the necessary lift and thrust. Insects and some small birds have even the ability to fly hover.The present study is focused on the modeling of wing flapping motion. Instead of only accommodating flapping motion in a vertical plane and spanwise pitching motion, the model permits to include wing lead-lag motion in the horizontal plane. This more degree of freedom permit to model more complex wing flapping motion.

• Periodical: Applied Mechanics and Materials (Volume 842)
• Pages: 132-140
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.842.132
• Online since: June 2016
• Authors: Tien Dat Nguyen, Subhan Sdywaliva, Taufiq Mulyanto*
• Keywords: Flapping UAV, Strip Theory, Wing Flapping Motion, Wing Lead-Lag Motion

References

[1] Matej KARASEK, Robotic hummingbird: Design of control mechanism for a hovering flapping wing micro air vehicle, Doctoral thesis, Universite Libre de Bruxelles, (2014).

[2] W. Shyy, H. Aono, S.K. Chimakurthi, P. Trizila, C-K. Kang, C.E.S. Cesnik, H. Liu, Recent progress in flapping wing aerodynamics and aeroelasticity, progress in Aerospace Sciences 46 (2010) 284- 327, Elsevier, (2010).

DOI: 10.1016/j.paerosci.2010.01.001

[3] B. Bruggeman. Improving flight performance of Delfy II in hover by improving wing design and driving mechanism". Master, s thesis, Delft University of Technology, (2010).

[4] M. T. Keennon, K. R. Klingebiel, H. Won, and A. Andriukov. Development of the nano hummingbird: A tailless flapping wing micro air vehicle,. AIAA paper 2012-0588, pages 1-24, (2012).

DOI: 10.2514/6.2012-588

[6] J.D. DeLaurier, An aerodynamic model for flapping-wing flight, Institute of Aerospace Studies, University of Toronto, Downsview, Oritario, Canada, The AERONAUTICAL JOURNAL OF THE ROYAL AERONAUTICAL SOCIETY, APRIL, (1993).

DOI: 10.1017/s0001924000026002

[7] M. Afzaal Malik, Farooq Ahmad, Effect of Different Design Parameters on Lift, Thrust and Drag of an Ornithopter, WCE2010, June 30 – July 2, London, U. K, (2010).

[8] Harijono Djojodihardjo, Kinematic and Aerodynamic Modelling of Flapping Wing ornithopter, International Conference on Advances Science and Contenporary Engineering, SciVerse Science Direct, (2012).

DOI: 10.1016/j.proeng.2012.10.093
