A Numerical Method of the Flexible Pavement Supported by SSC on Expansive Soil

Abstract:

Many road and highway have been constructed over the expansive soil in Java island without proper soil improvement for the subgrade. The behavior of the column on the expansive soil needs for study numerically and large scale. In this study, a numerical analysis is performed to study the effect of swelling on the deformation of the soil stabilized column supported flexible pavement. The main focus of the research is to obtain the deformation due to swelling and vehicle loading. The methodology including comparison the differential settlement of the soil stabilized column supported flexible pavement and unsupported flexible pavement as control model. The numerical analysis was modeled using finite element method. The simulations result that the column installation to support flexible pavement reduced the heaving and differential settlement of the pavement effectively. In case the overlay was performed for rehabilitation and maintenance of the pavement, the mini-columns can be installed before the overlay works. However, the conclusions of the study were limited to the result of numerical modeling that depended on the applied material model and volumetric swelling.

• Periodical: Applied Mechanics and Materials (Volume 845)
• Pages: 62-69
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.845.62
• Online since: July 2016
• Authors: Agus Setyo Muntohar*
• Keywords: Expansive Soil, Finite Element Method, Flexible Pavement, Mini-Column, Numerical Model

References

[1] A.S. Muntohar: Civ. Eng. Dimens., Vol 8, No. 2, ( 2006), pp.106-110.

[2] Hermawan, and G. Hasibuan, Uji Pengembangan Tanah Ekspansif Tiga Dimensi Di Kabupaten Gresik, Provinsi Jawa Timur, Buletin Geologi Tata Lingkungan, Vol. 22 No. 1 (2012), p.9 – 18.

[3] H.C. Hardiyatmo, and B. Suhendro, Perilaku Sistem Cakar Ayam Modifikasi pada Tanah Ekspansif, Researh Report Program Insentif 2009 Kementerian Negara Riset dan Teknologi, Department of Civil and Environmental Engineering, Universitas Gadjah Mada, Yogyakarta, (2010).

[4] V.B. Swamy, Stabilisation of Black Cotton Soil by Lime Piles, M. Sc. (Eng. ) Thesis, Indian Institute of Science (unpublished). (2000).

[5] M.C. Tonoz, C. Gokceoglu, and R. Ulusay: Bull. Eng. Geol. Environ., Vol. 62 (2003), p.91–106.

[6] A.S. Muntohar (2003). Lime-column in expansive soil: a study on the compressive strength, The International Conference on Civil Engineering (ICCE), 1-3 October 2003, Brawijaya University, Malang, Indonesia (CD ROM).

[7] S.M. Rao, and T. Thyagaraj: Proc. Inst. Civ Eng. – Geotech. Eng., Vol. 156, (2003), p.139–146.

[8] E. Hewayde, H. El Naggar, and N. Khorshid: Proc. Inst. Civ Eng. – Ground Improv., Vol. 9 No. 2, (2005), p.79 –87.

[9] A. Nazef, H. Lee, S. Chun, J. Greene, Evaluation of Soil Stabilized Columns Used for Flexible Pavement Embankment Support and Settlement Control, Report No. FL/DOT/SMO/13-561 Department of Transportation State of Florida, (2013).

[10] M.R. Malekpoor, and G. Poorebrahim: KSCE J. Civ. Eng., Vol. 19 No. 4, (2015), pp.893-903.

[11] A.S. Muntohar, Improvement of Expansive Subgrade Using Column Technique of Carbide Lime and Rice Husk Ash Mixtures, Proceedings of Soft Soil 2014, 20–23 October 2014, Bandung, Indonesia, p. I4. 1 – I4. 6, (2014).

[12] K-T. Leena, and L. Rainer, Modeling of the stress state and deformations of APT tests. Proceeding of the 2nd International Conference on Accelerated Pavement Testing, September 26–29, 2004, Minneapolis, Minnesot, USA, (2004) (CD ROM).

[13] S. A. Tan, and K. K. Oo, Stone column FEM modeling—2D and 3D considerations illustrated by case history. Proc., Int. Symp. on Tsunami Reconstruction with Geosynthetics, Asian Center for Soil Improvement and Geosynthetics, December 8-9, 2005, Bangkok, Thailand, p.157.

[14] C.C. Hird, I.C. Pyrah, and D. Russell: Géotechnique, Vol. 42 No. 3, (1992), p.499–511.

[15] M.A. Ismail, and M. Shahin, Finite Element Analyses of Granular Pile Anchors as a Foundation Option for Reactive Soils, in Shahin, M. and Nikraz, H. (eds), International Conference on Advances in Geotechnical Engineering (ICAGE 2011), November 7-9 2011, Perth, W. A, pp.1047-1052.

[16] A.N. Aljorany, S.F. Ibrahim, and A.I. Al-Adly: J. Eng., Vol. 20(4), (2014), pp.1-22.

[17] O. Jenck, D. Dias, and R. Kastner: J. Geotech. Geoenviron. Eng., Vol. 133 No. 3, (2007), pp.295-305.
