Analysis on the Causes of Fatigue Accidents of a Bolt-Ball Structure Plant in Shanxi

Abstract:

This paper take a bolt-ball node network frame factory building collapse in shanxi as the research background,it suddenly had a partial collapse after used 13 years. Based on the field testing,fracture analysis and theoretical calculation with the finite element analysis software ABAQUS and MIDAS,including the simulating of the M33 high streng bolt’s stress concentration factor and the analysis of the grid structure’s force conditions, we found the cause of the high strength bolt’s fatigue fracture ,and finally,we concluded that this was a rare low cycle fatigue destruction under the action of indirect dynamic load.

• Periodical: Applied Mechanics and Materials (Volume 851)
• Pages: 864-869
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.851.864
• Online since: August 2016
• Authors: Jian Lin, Hong Gang Lei*
• Keywords: Accident, Bolt-Ball Grid Structure, Fatigue Fracture, High Strength Bolt

References

[1] Y. J. Wang, Analysis on the cause of the collapse accident of a certain factory building, Build. Tech. 39(7) (2008) 551-553.

[2] D. Y. Yin, Analysis of the cause of the quality accident of the grid structure, J. Build. Struct. (1) (1988) 15-23.

[3] H. G. Lei, Y. Li, J. F. Jiao, Analysis of M20 high-strength bolt fatigue fracture of grid structure with bolt ball joints, Steel Struct. Eng. Res. supplement: (2004) 363-370.

[4] H. G. Lei, J. H. Wu, Analysis of factors affecting the fatigue of high strength bolts in bolted sphere joint space truss structures, The Friends Sci. (14) (2011) 1-3.

[5] S. J. Tian, Fatigue analysis and experimental verification of existing bolt ball grid structure M27 high strength bolt, Taiyuan university of technology master's degree thesis, (2015).

[6] H. G. Lei, Study on static and fatigue behavior of welded hollow spherical joints of grid structure, J. Build. Struct. (1) (1993) 2-7.

[7] H. G. Lei, The data reanalysis of the constant amplitude fatigue test of bolt ball joints, Steel Struct. Eng. Res. (2000) 202-205.

[8] H. G. Lei, L.J. Deng, Y. J. Yan et al, Analysis of fatigue influencing factors of high-strength bolt in grid structure with bolt ball joints, Steel Struct. Eng. Res. Supplement, (2002) 217-222.

[9] L. Ge, Fail the analysis of collapse of frame structure caused by corrosion, Taiyuan university of technology master's degree thesis, (2014).

[10] X. J. Feng, X. S. Lin, W. Pan, The fatigue performance of the bolt-ball nodes rack under the influence of suspension crane, J. Build. Struct, (4) (1995) 3-12.
