Study of Load Distribution and Sharing Characteristics of Planetary Geartrain for Wind Turbines

Abstract:

Most wind turbine gearboxes and pitch/yaw reducers consist of several planetary geartrains. Planetary geartrains allow gearboxes to be small, light, low noise, and efficient. The most important factors in the planetary geartrain design are load sharing among the planet gears and load distribution on the gear tooth flank. This study was conducted to analyze the load sharing and distribution in reducers with and without a slewing bearing. Load sharing and distribution of a pitch reducer without a slewing bearing were very uniform and even. However, in the other case, they were non-uniform and uneven, and the gear meshes were formed on the right or left. These results show that heavy loads act on the right or left flank of a meshed gear pair and reduce the gear life. Therefore, the slewing bearing must be considered when pitch/yaw reducers are designed and analyzed.

You might also be interested in these eBooks

Advances in Power Transmission Science and Technology

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 86)

Pages:

674-679

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.86.674

Citation:

Cite this paper

Online since:

August 2011

Authors:

Jeong Gil Kim, Geun Ho Lee, Young Jun Park, Yong Yun Nam, Tae Hyong Chong

Keywords:

Face Load Factor, Gear Tooth Flank Load, Load Distribution, Load Sharing, Pitch/Yaw Reducer, Planetary Gear Train, Wind Turbine (WT)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] K.H. Lee, G.H. Lee, I.H. Bae, J.S. Lee and T.H. Chong : Analysis of Structural Characteristics of Power-Split Type Planetary Geartrain (Spring Conference KSNRE, South Korea 2008).

Google Scholar

[2] A. Singh: Optimizing Gearset Durability in Double Pinion Planetary Transmissions (Proceedings of FISITA, France 2006).

Google Scholar

[3] A. Singh: Influence of Planetary Needle Bearings on the Performance of Single and Double Pinion Planetary Systems (ASME J. Mech. Des., USA 2007).

DOI: 10.1115/detc2005-84728

Google Scholar

[4] A. Singh, A. Kahraman, and H. Ligata: Internal Gear Strains and Load Sharing in Planetary Transmission: Model and Experiments (ASME J. Mech. Des., USA 2008).

DOI: 10.1115/detc2007-35047

Google Scholar

[5] ISO 6336: Calculation of Load Capacity of Spur and Helical Gears (2006).

DOI: 10.3403/30449594

Google Scholar

[6] AGMA 6123-B06: Design Manual for Enclosed Epicyclic Metric Module Gear Drives (2006).

Google Scholar

[7] H. Ligata, A. Kahraman and A. Singh: An Experimental Study of the Influence of Manufacturing Errors on the Planetary Gear Stresses and Planet Load Sharing (ASME J. Mech. Des., USA 2008).

DOI: 10.1115/1.2885194

Google Scholar
