Technical and Economic Analysis for Harmonic Distortion Impact and Mitigation Technique in Power Networks

Abstract:

This research proposes technical and economic analysis of harmonic distortion impact and mitigation technique in power networks. Main proposal of research is analysis of harmonic impact and harmonic solution by regarding to economic decency for investment. Parallel resonance is harmonic impact that will be mentioned in this research because it is a problem that is mostly emerged in industries that contain non-linear loads and power factor correction devices. Its impact on power network is high voltage and current amplification, which link to equipment and system failure. An application of detuned filter will be proposed to solve the problem due to its popularity (It is a basic solution, easier and more inexpensive than the other solution). Parallel resonance condition will be modeled with an industrial power network, which contains a power transformer, a non-linear load (AC drive), a power factor correction device (capacitor bank) and a harmonic correction device (detuned filter bank), by using electrical, mathematical and payback period formulas. The results will illustrated the impact of parallel resonance phenomenon due to harmonic distortion in power network.

• Periodical: Applied Mechanics and Materials (Volume 866)
• Pages: 439-443
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.866.439
• Online since: June 2017
• Authors: Nattachote Rugthaichareoncheep*, Saran Chaladying
• Keywords: Harmonic Distortion Impact, Harmonic Mitigation Technique, Payback Period Method

References

[1] The Institute of Electrical and Electronics Engineers (IEEE), Reccomended Practice and Requirements for Harmonic Control in Electric Power Systems, IEEE Std. 519-2014 (Rev. of IEEE Std. 519-1992). (2014).

[2] The Institute of Electrical and Electronics Engineers (IEEE), Definitions for the Measurement of Electri Power Quantities Under Sinusoidal, Nonsinusoidal, Balanced, or Unbalanced Conditions, IEEE Std. 1459-2010. (2010).

DOI: 10.1109/ieeestd.2010.5439063

[3] The International Electrotechnical Commission (IEC), Shunt Power Capacitor of the Self-Healing Type A.C. Systems Having Rated Voltage 1000V - Part 1, IEC Std. 60831-1. (2014).

[4] The International Electrotechnical Commission (IEC), Industrial A.C. Networks Affected by Harmonic – Application of Filters and Shunt Capacitor, IEC Std. 61642. (1997).

[5] J.C. Das, Power System Harmonics and Passive Filter Designs, A John Wiley & Sons, Inc., Canada, (2015).

[6] Roger C. Dugan, Mark F. Mcgranaghan, Surya Santoso, H. Way Beaty, Electrical Power Systems Quality, third ed., RR Donnelley, United State of America, (2012).

[7] Math H.J. Bollen, Irene Y.H. Gu, Signal Processing of Power Quality Disturbance, A John Wiley & Sons, Inc., Canada, (2006).

[8] Mark F. Mcgranaghan, Bill Roettger, Economic Evaluation of Power Quality, IEEE Power Engineering Review, vol. 22, 2002, pp.8-12.

DOI: 10.1109/39.981334

[9] Chaladying S., Charlangsut A., Rugthaichareoncheep N., Parallel Resonance Impact on Power Factor Improvement in Power System with Harmonic Distortion, IEEE Region 10 Annual Conference (TENCON2015). (2015).

DOI: 10.1109/tencon.2015.7373180

[10] D.E. Rice, A Detailed Analysis of Six-Pulse Converter Harmonic Currents, Petroleum and Chemical Industry Conference (Industry Application Society 39th Annual). (1992).

DOI: 10.1109/pcicon.1992.229315
