Microdroplet Detection of Precision Dispensing for Miniature Parts Assembly Technology

Abstract:

Microdroplet detection is the key for precision dispensing technology, which is widely applied in precise assembly of miniature parts, microelectronics packaging and biological tests. In order to measure droplet in micro scale for different working conditions, In this paper, an on-demand detection method--which is composed of statistical weighing detection to measure batch dispensing quality for large-scale production, real-time visual detection to measure droplet area and position accuracy for flexible production as well as pressing-plate method to measure nanoliter volume for single microdroplet detection--is presented. An automatic dispensing system to generate microdroplets is developed and the procedure of online detection based on machine vision of this dispensing system is introduced. Experimental results show that dispensing standard deviations measured by on-demand detection are 2.5 µg, 2.8 nl and 0.013 mm² for weighing method, real-time detection and pressing-plate method, respectively. The results also prove that the pressing-plate method can measure single micro droplet of 10 nl.

• Periodical: Applied Mechanics and Materials (Volume 868)
• Pages: 328-333
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.868.328
• Online since: July 2017
• Authors: Qing Qing Zhang, Xiao Dong Wang*, Zheng Xu, Ping Zhu
• Keywords: Machine Vision, Microdroplet Detection, Precision Dispensing, Quality Evaluation

References

[1] Li Fudong, Xu De, Zhang Tianping, Technology Developments of Micro Fluid Dispensing, J. Lecture Notes in Electrical Engineering 360, Springer-Verlag Berlin Heidelberg. 2. (2016) 171-180.

[2] Sun Daoheng. Gao Junchuan, Du Jiang, et al. Advances in Fluid Dispensing Technology for Micro-electronics Packaging, J. China Mechanical Engineering, 20. 22. (2011) 2513-2519.

[3] Chen X B, Zhan g W J , Schoenau G , et al. Off -Line Control of Time - Pressure Dispensing Processes for Electronics Packaging, J. IEEE Transactions on Electronics Packaging Manufacturing, 4. 26 (2003) 286 -293.

DOI: 10.1109/tepm.2003.820824

[4] Chen Jiankui, Guo Xiqian, Yin Zhouping, et al. A Detection Algorithm of Micro Adhesive Drops for Manufacturing of Flexible RFID Tags, J. China Mechanical Engineering, 6. 26 (2015) 789-793.

[5] Chen Congping, Fang Zifan, Qin Wu, et al. Measuring Micro Adhesive Dot Volume Based on Single Gray Image, J. Computer Measurement & Control, 10. 18 (2010) 2238-2240.

[6] Kyesi Kwon, Speed Measurement of Ink Droplet by Using Edge Detection Techniques, J. Measurement, 42 (2009) 44–50.

DOI: 10.1016/j.measurement.2008.03.016

[7] Chen Chihyen, Weng Chunjen, Hwang, Chi-Hung, et al. A Study of Video-based Droplet Detection, Instrumentation and Measurement Technology Conference, (2015) 1014-1018.

[8] Kondo T, Kamba S, Suzuki T, et al. Detection of Sub-microliter Liquid droplets Using a Metamaterial Mesh Sensor. Proceedings of IEEE Sensors, (2014) 547-550.

DOI: 10.1109/icsens.2014.6985056

[9] Caglar Elbuken, Tomasz Glawdel, Danny Chan . Detection of microdroplet size and speed using capacitive sensors. J. Sensors and Actuators A: Physical. 2. 171 (2011) 55-62.

DOI: 10.1016/j.sna.2011.07.007

[10] Mutschler K, Ernst A, Paust N, Zengerle R, Koltay P. Capacitive Detection of Nanoliter Droplets on The Fly-investigation of Electric Field During Droplet Formation Using CFD-simulation. Solid-state Sensors, Actuators & Microsystems Conference 17. 2 (2011).

DOI: 10.1109/transducers.2011.5969570

[11] J. Tröndlea, A. Ernsta,W. Streuleb. Non-contact Optical Sensor to Detect Free Flying Droplets in The Nanolitre Range. Sensors and Actuators A 158 (2010) 254–262.

DOI: 10.1016/j.sna.2010.01.023
