The Analysis and Design of Closed-Loop Control System for MEMS Vibratory Gyroscopes

Abstract:

A digital closed-loop control system with all digital phase locked loop (ADPLL) is designed and optimized, in order to improve the bias stability and transient response of the gyroscope. The nonlinear mathematical models for the closed-loop amplitude and phase control system are established. The linearization method is applied to analyze the nonlinear models. The control parameters of the drive loop are optimized. The experimental results show that the phase deviation between the demodulation reference signal of the drive loop and the sense signal is less than 0.25° in the temperature range from-40°C to 60°C, within 0.15° of the variation. At room temperature, the overshoot amount of the gyroscope control system is 4.5% with setting time of 0.12s. The bias stability is 1.45°h. Compared to the analog control scheme, the digital control system has advantages of short setting time, small overshoot, short phase locked time, large locked range, high phase precision, etc.

• Periodical: Applied Mechanics and Materials (Volume 868)
• Pages: 51-57
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.868.51
• Online since: July 2017
• Authors: Jia Xin Yu*, Qin Shi, Guo Ming Xia, An Ping Qiu, Xue Hao Yu, Zhong Hai Pei
• Keywords: All Digital Phase Locked Loop, Digital Control System, MEMS Vibratory Gyroscopes

References

[1] Zotov S A, et al. Utilization of Mechanical Quadrature in Silicon MEMS Vibratory Gyroscope to Increase and Expand the Long Term In-run Bias Stability, International Symposium on Inertial Sensors and Systems, (2014) 1-4.

DOI: 10.1109/isiss.2014.6782536

[2] W. ZHOU, et al. Drive Loop Design of Single Axis Gyroscope Based on SOPC, Journal of Chinese Inertial Technology, (2009) 67-70.

[3] G. Xia. Digital Technology Based Silicon Micro Gyroscope Performance Stability Study, Southeast University, (2011) 87-92.

[4] B. Razavi. Design of Analog CMOS Integrated Circuits, McGraw-Hill, Inc. 2000，pp.434-451.

[5] Bishop, H. Robert. Modern control system, Science Press, (2005).

[6] J. dong, et al. Control Engineering Foundation, Tsinghua University Press, 2015, pp.87-89.
