Numerical Analysis of Thermal Error for a 4-Axises Horizontal Machining Center

Abstract:

Thermal deformations of machine tool are among the most significant error source of machining errors. Most of current thermal error modeling researches is about 3-axies machine tool, highly reliant on collected date, which could not predict thermal errors in design stage. In This paper, in order to estimate the thermal error of a 4-axise horizontal machining center. A thermal error prediction method in machine tool design stage is proposed. Thermal errors in workspace in different working condition are illustrated through numerical simulation and volumetric error model. Verification experiments shows the outcomes of this prediction method are basically correct.

• Periodical: Applied Mechanics and Materials (Volume 868)
• Pages: 64-68
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.868.64
• Online since: July 2017
• Authors: Yu Bin Huang*, Wei Sun, Qing Chao Sun, Yue Ma, Hong Fu Wang
• Keywords: Experimental Verification, Finite Element Analysis, Machine Tool, Thermal Error
