Integration of Cutting Robot with CAD/CAM System Based on STEP-NC

Abstract:

In order to solve the problem of openness, intelligence and low integration in the current machining robot control system, STEP-NC standard is introduced into the field of robot machining, and defines the STEP-NC data model of industrial robots. The 6R industrial robots are used to build the machining platform and the connection between the machining robot and the CAD / CAM system and the integrated data stream structure are discussed. The key issues involved in the post processing of the machining robot are studied. Taking the 6R robot as an example, the robot prototype system is established, and the kinematics solution in the post-processing process is studied and deduced. The cutting and post-processing system platform of cutting robot was established and the sample art machining was completed. The experimental and simulation results show that the system can complete the machining process of the cutting robot and generate executable robot machining instructions.

• Periodical: Applied Mechanics and Materials (Volume 868)
• Pages: 93-98
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.868.93
• Online since: July 2017
• Authors: Li Jin Fang, Li Li, Guo Xun Wang*
• Keywords: CAD/CAM, Cutting Robot, Post-Processing, STEP-NC

References

[1] R. Devlieg. High-accuracy robotic drilling/milling of 737 inboard flaps. SAE Int. J. Aerosp., 4(2011) 1373-1379.

DOI: 10.4271/2011-01-2733

[2] S. Bi, J. Liang. Robotic drilling system for titanium structures. Int. J. Adv. Manuf. Technol, 54(2011) 767-774.

DOI: 10.1007/s00170-010-2962-2

[3] W. L. Xiao, H. Ji. Integration of a cutting robot with CAD/CAM system. J Mech Eng, 15(2011) 52-60.

[4] W. Zhu, W. Qu, L. Cao, et al. An off-line programming system for robotic drilling in aerospace manufacturing. Int. J. Adv. Manuf. Technol, 68(2013)2535-2545.

DOI: 10.1007/s00170-013-4873-5

[5] S. Mitsi, K. D. Bouzakis, G. Mansour, et al. Off-line programming of an industrial robot for manufacturing. Int. J. Adv. Manuf. Technol, 26(2005) 262-267.

DOI: 10.1007/s00170-003-1728-5

[6] J. Du, X. Yan, X. Tian, L. Liu. Code conversion technology from STEP-NC-based part programs into G-code for milling. Comput Integra Manuf Sys, 16 (2010)188-194.

[7] M. Minhat, V. Vyatkin, X. Xu, S. Wong. A novel open CNC architecture based on STEP-NC data model and IEC 61499 function blocks. Robot Cim-Int Manuf , 25 (2009)560-569.

DOI: 10.1016/j.rcim.2008.03.021

[8] W.L. Xiao, H. Ji, S.X. Dong. A STEP-compliant Industrial Robot Data Model for robot off-line programming systems. Robot Cim-Int Manuf, 30(2014) 114-123.

DOI: 10.1016/j.rcim.2013.09.007
