Power Quality Measurements of a Horizontal Axial Small Wind Turbine

Abstract:

As small wind turbines are increasingly used, the assessments of power quality may thus become paramount. Unlike the large-scale wind turbines which are optional required to perform power quality measurements during production certification stage; however the power quality measurements are often neglected in small wind turbines since they are not requested on the certain of national grid codes at low-voltage distribution system level. Considering the high penetrations of small wind turbines may be connected to the future urban electric network, the paper performs the power quality on-site measurements of a horizontal axle small wind turbines. The issues may include the discussion of measurement system structure, the description of measurement method, and the analysis of wind turbine power characteristic, voltage/current trends, harmonics and flicker phenomena. The measured data collected in the study will valuable for the further analysis of power systems connected with the small wind turbines.

• Periodical: Applied Mechanics and Materials (Volume 870)
• Pages: 329-334
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.870.329
• Online since: September 2017
• Authors: Yu Jen Liu*, Yen Chang Chen, Pei Hsiu Lan, Tsang Pin Chang
• Keywords: Flicker, Harmonics, Power Quality, Power System, Small Wind Turbine

References

[1] U.S. Department of Energy, Small Wind Electric Systems: A New York Customer's Guide, (2005).

[2] A. Abrantes, Overview of power quality aspects in wind generation, IEEE North American Power Symposium, Champaign, IL USA. (2012).

DOI: 10.1109/naps.2012.6336402

[3] M. J. Ortegaa, J. C. Hernandeza, and O. G. Garciab, Measurement and assessment of power quality characteristics for photovoltaic systems: harmonics, flicker, unbalance, and slow voltage, variations, Electric Power Systems Research (EPSR), 96 (2013).

DOI: 10.1016/j.epsr.2012.11.003

[4] IEC 61400-12-1 standard: wind turbines - part 12-1: power performance measurements of electricity producing wind turbines. (2005).

DOI: 10.3403/30434175

[5] IEC 61000-4-7 standard: electromagnetic compatibility (EMC) - part 4-7: testing and measurement techniques - general guide on harmonics and interharmonics measurements and instrumentation, for power supply systems and equipment connected thereto. (2002).

DOI: 10.3403/02743713

[6] A. Novitskiy, and H. Schau, Analysis of a ratio between delta V10 and Pst flicker criteria, IEEE Universities' Power Engineering Conference (UPEC), Soest, Germany. (2011).
