Process Optimization of Ethyl Ester Biodiesel Production from Used Vegetable Oil under Sodium Methoxide Catalyst and its Purification by Ion Exchange Resin

Abstract:

Production of ethyl ester biodiesel from a tranesterification reaction of used vegetable oil and ethanol was carried out using a sodium methoxide catalyst. Response surface methodology (RSM) was applied to investigate the effect of experimental factors on the fatty acid ethyl ester (FAEE) conversion. The design of the experiment involved a 5-level-4-factor central composite design and 30 runs were used to achieve the optimum percentage FAEE conversion that was determined by 1H-NMR. The coefficient of determination (R2) for the regression equation was 86.49% and the probability value (p<0.05) demonstrated a very good fit for the regression model. The optimum conditions obtained from RSM were 4% v/v of catalyst, 35.61% v/v of ethanol-to-oil, at 43.70°C reaction temperature, and 75.45 min of reaction time. The produced ethyl ester biodiesel was further purified by wet washing compared with dry washing using ion exchange resin. The result showed that the purified biodiesel by wet washing met the EN standard but the dry washing out put did not but only for the acid value. The blending of 10% v/v of purified biodiesel obtained from dry washing with 90% v/v of petrodiesel could decrease the acid value to meet the EN standard.

• Periodical: Applied Mechanics and Materials (Volume 873)
• Pages: 89-94
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.873.89
• Online since: November 2017
• Authors: Sureerat Namwong, Vittaya Punsuvon*, Wallop Arirop
• Keywords: Biodiesel, Ethanol, Optimization, Response Surface Methodology, Used Vegetable Oil

References

[1] A. B. Fadhil, W. S. Abdulahad, Production of chicken fat ethyl esters via optimized protocols with dry washing by silica gel, Int. J. Green Energy. 13 (2016) 538-545.

DOI: 10.1080/15435075.2014.962034

[2] S. Namwong, V. Punsuvon, Biodiesel production from used vegetable oil using ethanol and sodium methoxide catalyst, Key Eng. Mater. 723 (2017) 551-555.

DOI: 10.4028/www.scientific.net/kem.723.551

[3] R. Guzatto, D. Defferari, Q. B. Reiznautt, Í. R. Cadore, D. Samios, Transesterification double step process modification for ethyl ester biodiesel production from vegetable and waste oils, Fuel. 92 (2012) 197-203.

DOI: 10.1016/j.fuel.2011.08.010

[4] K. T. Lee, A. M. Mohtar, S. Zainudin, A. R. Mohamed, Optimum conditions for preparation of flue gas desulfurization absorbent from rice husk ash, Fuel. 84 (2015) 143-151.

DOI: 10.1016/j.fuel.2004.08.018

[5] X. Yuan, J. Liu, G. Zeng, J. Shi, J. Tong, G. Huang, Optimization of conversion of waste rapeseed oil with high FFA to biodiesel using response surface methodology, Renew. Energy. 33 (2008) 1678–1684.

DOI: 10.1016/j.renene.2007.09.007

[6] G. Vicente, A. Coteron, M. Martinez, J. Aracil, Application of the factorial design of experiments and response surface methodology to optimize biodiesel production, Ind. Crops Prod. 8 (1998) 1-45.

DOI: 10.1016/s0926-6690(97)10003-6
