A Research on Technology for Manufacturing Body Shell of Anti-Tank Rocket

Abstract:

Body shell of anti-tank rocket which is a pipe part working under extreme conditions of high pressure and temperature, is manufactured from low-alloyed high quality steel 30X3MФ. The steel 30X3MΦ made in Vietnam appropriates of standard to produce body shell anti-tank rocket. The shell ensure technical requirements of composition, with very low rate of P, S and has good mechanical properties. After casting, steel billets were backward extrusion, includes 3 steps of thinned stamp, heat treatment and drawing processes, body shell fabrication is satisfied requirment of technique for anti-tank rocket shell. Results of fire testing of the body shells are in agreement with that of Russian ammunition. The body shells of anti-tank rocket which were manufactured in Vietnam conditions, satisfied desired technical requirement.

• Periodical: Applied Mechanics and Materials (Volume 889)
• Pages: 131-139
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.889.131
• Online since: March 2019
• Authors: Bui Khac Khanh*, Nguyen Ha Tuan, Vu Trung Tuyen, Nguyen Truong Huy
• Keywords: Backward Extrusion, Body Shell of Anti-Tank Rocket, Heat Treatment, Steel 30X3MФ

References

[1] R.O. Davidson, Research and development of materiel, Headquarters United States Army Materiel Command Washington, D.C 20315, 31 July (1964).

[2] Le Trung Kien, Le Gia Bao, Pressing mold design and manufacturing, Publishing house of Hanoi University of Science & Technology, (2016).

[3] Kai Zhang, Hao Yu, Jun-you Liu, Yan-xia Li, Jian Liu and Jia-liang Zhang, Microstructure and property of a functionally graded aluminum silicon alloy fabricated by semi-solid backward extrusion process, Materials Science & Engineering A 624 (2015) 229–238.

DOI: 10.1016/j.msea.2014.11.044

[4] Masatoshi Sawamura, Yasuhiro Yogo, Michiaki Kamiyama and Noritoshi Iwata, Measurement of friction coefficient by backward extrusion withrotating tool under severe forming conditions, ScienceDirect Procedia Engineering 81 ( 2014 ) 1866 – 1871.

DOI: 10.1016/j.proeng.2014.10.247

[5] K.Abrinia and S.Orangi, Numerical study of backward extrusion process using finite element method, School of Mechanical Engineering, College of Engineering, University of Tehran, I.R. Iran, (2010).

DOI: 10.5772/10219

[6] Taylan Altan, ERC/NSM, Ohio State University Gracious Ngaile, North Carolina State University, Gangshu Shen, Ladish Company, Cold and Hot forging Fundamentals and Applications, ASM International@ Materials Park, OH 44073-0002, (2005).

DOI: 10.31399/asm.tb.chffa.9781627083003

[7] Dipl.-Ing. Jürgen Schemmel, Beschreibung des Verformungs Festigkeits-undVersagensverhaltensvon Komponenten im Kriechbereich unter instationärer Beanspruchungmit einem elastisch-viskoplastischen Werkstoffmodell, Materialprüfungsanstalt Universität Stuttgart (2003).

[8] W.H. Sillekens, Backward Can Extrusion and Meterials Behavior, 5 June (1992).

[9] A research on manufacturing technology steel and body shell of anti-tank rocket, Summary report of Scientific and Technical report, General Department of Defense Industry, Hanoi (2016).
