Study on the Cutting Properties of the Singer Layer Metal Bonded cBN Grinding Wheel by Electroplating in Grinding of Heat-Treated Steel SKD11

Abstract:

This article presents preliminary investigations on the cutting ability of the singer layer metal-bonded cBN grinding wheel manufactured by electroplating method at Vietnamese laboratory. The cutting ability of the grinding wheel is evaluated by two factors: grinding ratio G and surface roughness of workpiece. These results are compared to those of the Japanese grinding wheels. The experimental results showed that the fabricated cBN grinding wheel has good cutting ability with high grinding ratio G. The value of the grinding ratio was 600 to 1800 in the grinding process of SKD11 steel (hardness of 62-63HRC) at the grinding speed V of 12.56m/s, feed rate S of 300mm/min, depth of cut t of 0.01mm. The maximum grinding ratio (1800) is equivalent to the average grinding ratio of the Japanese grinding wheel. The grinding ratio is also maintained up to 26 cutting hours. The good grinding surface was achieved with the average Ra of 2.5μm. In addition, the bonding of cBN abrasive to the wheel body was observed with scanning electron microscope (SEM) of the surface of grinding wheel after the cutting process. The SEM image shown that the cBN abrasive particles were not removed from the wheel surface.

• Periodical: Applied Mechanics and Materials (Volume 889)
• Pages: 80-86
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.889.80
• Online since: March 2019
• Authors: Truong Hoanh Son, Tran Thi Van Nga
• Keywords: cBN Abrasive, Cutting Ability, Electroplating Method, Grinding Ratio, Singer Layer Metal Bonded cBN Grinding Wheel, Surface Finish

References

[1] S. Malkin, Machining with abrasive-Grinding Technology, E. Horwood, (1989).

[2] Tran Thi Van Nga, Truong Hoanh Son and Tran Vinh Hung, Research on influence of current density and plating time to the distribution of abrasive grit in fabricating cBN electroplated grinding wheel, Vietnam mechanical Engineering Journal. 1+2, (2017), 127-133.

[3] Tran Thi Van Nga, Truong Hoanh Son and Tran Vinh Hung, A research on manufacturing technology of monolayer grinding wheel and the first step of manufacturing cBN grinding wheel using electroplating method, Journal of Sience and Technology, Hanoi University of Industry, 27 (2015), 130-133.

DOI: 10.1299/jsmelem.2005.2.685

[4] Nguyen Duc Hung, Tran Thi Van Nga and Mai Van Phuoc, Thickness determination and control of functional Ni-composite electrodeposited coatings, Journal Science and Technology, Vietnam Academy of Science and Technology, 55(1B), (2017), 1-6.

DOI: 10.15625/2525-2518/55/1b/12084

[5] Tran Thi Van Nga and Truong Hoanh Son, Experimental study on the surface formation of cBN metal bond grinding wheel by electroplating method, Proceeding of the national science and technology conference on mechanical- transportation engineering (NSCMET) (2016), 134-138.

[6] Tran Thi Van Nga and Truong Hoanh Son, Research on application composite electroplating to fabricate grinding tool, International Cooperation Issue of Transpotation (Especial Issue, No.06), (2015), 80-84.
