Analysis of Magneto Rheological Fluid Journal Bearing

Abstract:

Magneto Rheological (MR) fluids are a class of smart materials where the shear stress is not directly proportional to rate of shear. The viscosity of fluid changes as magnetic field changes and hence this phenomenon is very useful in bearing-rotor system for attenuating the vibrations. In the present study the application of MR fluid as lubricant instead of Newtonian fluid in the journal bearing is explored through steady state, dynamic characteristics and stability. MR fluid film has been modeled as per Bingham rheological model. FEM with three node triangular elements has been used to solve the Reynolds equation both for the Newtonian fluid film and MR fluid film. The results show the load carrying capacity in the case of MR fluid journal bearing is higher than that of using the Newtonian fluid. The load carrying capacity increases with the increasing magnetic field for all eccentricity ratios. The results also show better stability of the bearing using MR fluid at higher eccentricity ratios. The unbalance response of the rotor mounted on the journal bearing using MR fluid is also estimated to be lower than that of with the Newtonian fluid.

• Periodical: Applied Mechanics and Materials (Volume 895)
• Pages: 152-157
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.895.152
• Online since: November 2019
• Authors: B. Narasimha Rao, A. Seshadri Sekhar*
• Keywords: Bingham Model, Damping Coefficients, Finite Element Method, Hydrodynamic Journal Bearing, MR Fluid, Newtonian Fluid, Stiffness Coefficient

References

[1] R.G. Kirk and E.J. Gunter, Short bearing analysis applied to rotor bearing dynamics, Part I: Theory, Trans. ASME, J. Lub. Tech. 98 (1976) 47-56.

DOI: 10.1115/1.3452771

[2] R.G. Kirk and E.J. Gunter, Short bearing analysis applied to rotor bearing dynamics, Part II: Results of journal bearing response, Trans. ASME, J. Lub. Tech., 98 (1976) 319-329.

DOI: 10.1115/1.3452838

[3] J.W. Lund and K.K. Thomson, A calculation Method and Data for the Dynamic Coefficients of Oil-lubricated Bearings, Topics in Fluid Film Bearing and Rotor-Bearing System Design and Optimisation, ASME, (1978) 1-28.

[4] P. Klit and J.W. Lund, Calculation of the Dynamic coefficients of a Journal bearing using a variational approach, Trans. ASME, J. Tribology, 108(1986) 421-425.

DOI: 10.1115/1.3261225

[5] J.W. Lund, Review of the Dynamic Coefficients for Fluid Film Journal Bearings, ASME 86-Trib-48 (1986).

[6] P.E. Allaire, Design of Journal Bearings for High Speed Rotating Machinery, Fundamentals of The Design of Fluid Film Bearings, ASME, (1979), 45-83.

[7] P.K. Goenka and J.F, Booker, Spherical Bearings: Static and Dynamic Analysis Via the Finite Element Method, Trans. ASME, J. Lub. Tech., 102 (1980) 308-319.

DOI: 10.1115/1.3251522

[8] P.K. Goenka, Dynamically Loaded Journal Bearings: A Finite Element Method, Analysis, Trans. ASME, J. Tribology, 106 (1984), 429-439.

DOI: 10.1115/1.3260958

[9] K.P. Gertzos, P.G. Nikolakopoulos and C.A. Papadopoulos, CFD analysis of journal bearing hydrodynamic lubrication by Bingham lubricant, Tribology International, 41(2008) 1190-1204.

DOI: 10.1016/j.triboint.2008.03.002

[10] D. A. Bompos, P. G. Nikolakopoulos, CFD Simulation of magnetorheological fluid journal bearings, Simulation Modelling and Practice theory, 19 (2011) 1035-1060.

DOI: 10.1016/j.simpat.2011.01.001

[11] Gonclaves, F.D. Characterizing the behaviour of Magneto rheological Fluids at High velocities and High Shear rates, Blacksburg, Virginia, (2005).

[12] Properties and applications of commercial magnetorheological fluids, Lord technical data.

[13] Majumdar, B.C, Introduction to Tribology of Bearings, S. Chand & Company Ltd., New Delhi, (2008).

[14] Osman T.A, G.S. Nada, Z.S. Safar, Static and dynamic characteristics of magnetized journal bearings lubricated with ferrofluid, Tribology international 34(2001) 369-380.

DOI: 10.1016/s0301-679x(01)00017-2

[15] Prabhu B.S. and SekharA.S., Dynamic analysis of Rotating Systems and Applications, Multi Science Publishing ltd Brentwood, UK, (2008).
