Analysis of Pounding Response for Simply Supported Skew Girder Bridge under Earthquake

Abstract:

Under the earthquake, pounding between the beam and the bridge abutment causes great damages to skew girder bridge, and current study on pounding response is still less as the collision effect is complex. In order to study the displacement and collision force under Elcentro and Tianjin ground motion, a three-dimensional finite element computational model for seismic pounding of a 16m simply supported skew girder bridge was established and nonlinear time-history analysis was carried out with pounding element designed to simulate the pounding effect between beam and abutment. The results show that the displacement of side beam is more than that of middle beam in simply supported skew girder bridge. The maximum collision force of the side beam is more than that of middle beam, and the beam pounds the abutment several times. Appropriate expansion joint width should be set according to the displacement of the side beam when the expansion joint designed.

• Periodical: Applied Mechanics and Materials (Volumes 90-93)
• Pages: 1234-1238
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.90-93.1234
• Online since: September 2011
• Authors: Qing Kai Sun, Xing Jun Qi, Yi Liu
• Keywords: Nonlinear Time-History Analysis, Pounding Unit, Seismic Response, Simply Supported Skew Girder Bridges

References

[1] Gan Xia, Rongguang Shao: Analysis of the Oblique Beam Structure. Jiangsu Science and Technology Press, 1995. (In Chinese)

[2] Lichu Fan, Jianzhong Li: Analysis of bridge damage of Wenchuan earthquake and Seismic Design Strategy. Highway, 2009, (5); 122-128. (In Chinese)

[3] Qiulin Zhuo: Seismic Response Analysis of Simple-Supported Skew Highway Girder Bridges. Fuzhou University, 2004, 12. (In Chinese)

[4] Lichu Fan, Shide Hu and Aijun Ye: Seismic Design of Long Span Bridges. Shanghai Tongji University，2000. (In Chinese)

[5] Shervin Maleki, V.Bisadi: Orthogonal Effects in Seismic Analysis of Skewed Bridges. Journal of Bridge.

[6] JTJ 004-89, Code for Seismic Design of Highway Engineering. (In Chinese)

[7] Lichu Fan: Seismic Design of Bridge. Shanghai: Tongji University Press, 1997. (In Chinese)
