Large Scale Triaxial Rheological Apparatus Development and Granular Soils Rheological Properties Analysis

Abstract:

To study the granular soil’s rheological properties, a large triaxial rheological apparatus was developed by assemblying a axial pressure and confining pressure providing equipments for the SZ30-4 large scale triaxial apparatus, and the stability examinations proved that the stability of this pressure providing equipments was competent for granular soil’s rheological tests. The large triaxial rheological apparatus have the axial pressure ranging from 0 to 1.0 MPa, confining pressure of 50kPa, 100kPa, 150kPa, 200kPa, 250kPa and the soil sample dimension of Φ=300mm, h=600mm. A series of granular soil creep tests were executed on this apparatus. The tests discussion shows that stress conditions are the main factors, which affects the creep properties of granular soil. There are different rheological properties at different stress level. eg. at low stress level (S=0.1) for the elastic, at middling stress level (0.20.8) for the non-linear viscous plastic. The total rheological strain nonlinearly increase with stress level increments but linearly increase with confining pressure increments. According to the discussion of redstone granular soil’s creep properties, a rheological component based on hyperbola function was presented, and a nonlinear viscous elastioplastic rheological constitutive model was set up by putting the component and the Burgers model in series. The creep properties analysis shows the rheological model can describe the granular soil’s whole rheological phase well.

• Periodical: Applied Mechanics and Materials (Volumes 90-93)
• Pages: 79-89
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.90-93.79
• Online since: September 2011
• Authors: Xiao Bin Chen, Jia Sheng Zhang
• Keywords: Granular Soil, Large Triaxial Rheological Apparatus, Rheological Constitutive Model, Rheological Test

References

[1] KARMAKAR S, SHARMA J, KUSHWAHA R L. Critical state elasto-plastic constitutive models for soil failure in tillage review, J. Can Biosyst Eng, 2004,Vol46(4):2-23.

[2] GHEZZEHEI T A. Rheological properties of wet soils and clays under steady and oscillatory stresses, J. Soil Sci Soc Am, 2001,Vol65(6):24–37.

DOI: 10.2136/sssaj2001.653624x

[3] FENG Xia-ting, CHEN Bing-rui. Identification of visco-elastic models for rocks using genetic programming coupled with the modified particle swarm optimization algorithm, J. International Journal of Rock Mechanics & Mining Sciences,2006,Vol 43 (2): 789-801.

DOI: 10.1016/j.ijrmms.2005.12.010

[4] GHABOUSSI J, PECKNOLD D A, ZHANG M, HAJALI R M. Autoprogressive training of neural network constitutive models, J. Numer Methods Eng, 1998,Vol42(a):105-126.

DOI: 10.1002/(sici)1097-0207(19980515)42:1<105::aid-nme356>3.0.co;2-v

[5] FURUKAWA T, SUGATA T, YOSHIMURA S. An automated system for simulation and parameter identification of inelastic constitutive models, J. Comput Methods Appl Mech Eng, 2002,Vol191(22):35-60.

DOI: 10.1016/s0045-7825(01)00375-9

[6] KARMAKAR S, KUSHWAHA R L. Development and laboratory evaluation of a rheometer for soil visco-plastic parameters, J. Journal of Terramechanics, 2007,Vol44 (3):197–204.

DOI: 10.1016/j.jterra.2006.10.002

[7] FINDLEY W N, LAI J S, ONARAN K. Creep and Relaxation of Nonlinear Viscous Materials. Dover Publication,UK, 1976.

[8] BONET J. Large strain viscoelastic constitutive models, J. Solids Structures, 2001,Vol38(8):2953-2968.

DOI: 10.1016/s0020-7683(00)00215-8

[9] WEI Li-de, XU Wei-ya, ZHU Zhen-de. Study on constitutive model of Viscoelastoplastic rock, J. Rock and Soil Mechanics,2002,Vol23(5): 583-586.

[10] XU Wei-ya. Investigation on triaxial theologicalmechanical properties of green schist specimen II1：model analysis, J. Rock and Soil Mechanics , 2005,Vol26(5):693-698.

[11] SUN Jun. Rheology of Geomaterial and Its Engineering Application. China Architecture and Building Press, 1999, Beijing.

[12] WAN R G., GUO P J. A Simple Constitutive Model for Granular Soils:Modified Stress-Dilatancy Approach, J. Computers and Geotechnics, 1998,Vol22(2):109-133.

DOI: 10.1016/s0266-352x(98)00004-4

[13] SHAMY U E, ZEGHAL M. A micro-mechanical investigation of the dynamic response and liquefaction of saturated granular soils, J. Soil Dynamics and Earthquake Engineering,2007,Vol 27 (6) :712–729.

DOI: 10.1016/j.soildyn.2006.12.010

[14] EVGIN E. An experimental study and numerical simulation of liquefaction at a soil-structure interface[R]. In Proceedings, 53rd Canadian geotechnical conference: geotechnical engineering at the dawn of the 3rd millennium (Montreal, 2000), Richmond, BC, Canada, Canadian Geotechnical Society, 2000, pp.1075-1082.

[15] LI L, HOLT R M. Simulation of flow in sandstone with fluid coupled particle model[R]. Proceedings, 38th U.S. rock mechanics symposium, Washington, DC, 2000,p.65–72.

[16] SHAMY U, ZEGHAL M. A coupled continuum-discrete model for saturated granular soils, J. Journal of Engineering Mechanics, 2005,Vol131(4):13-26.

DOI: 10.1061/(asce)0733-9399(2005)131:4(413)

[17] STEEN K. Characteristic state plasticity for granular materials Part I: Basic theory, J. International Journal of Solids and Structures,2000,Vol37 (2):6343-6360

DOI: 10.1016/s0020-7683(99)00278-4

[18] AKBULUTA S, SAGLAMER A. Modification of hydraulic conductivity in granular soils using waste materials, J. Waste Management,2004,Vol24 (4): 491–499.

DOI: 10.1016/j.wasman.2004.01.002

[19] ALI L. On the modeling of the state dependency of granular soils, J. Computers and Geotechnics,2009, Vol36 (7) :1237–1245.

DOI: 10.1016/j.compgeo.2009.06.003

[20] DAFALIAS Y F, MANZARI M T. Simple plasticity sand model accounting for fabric change effects, J. Eng Mech ,2004,Vol130(6):22–34.

DOI: 10.1061/(asce)0733-9399(2004)130:6(622)

[21] RAHHAL M E, LEFEBVRE G.. Understanding the effect of a static driving shear stress on the liquefaction resistance of medium dense granular soils, J. Soil Dynamics and Earthquake Engineering, 2000,Vol20 (4):397-404

DOI: 10.1016/s0267-7261(00)00089-0

[22] CHANG C S, HICHER P Y. An elasto-plastic model for granular materials with microstructural consideration, J. Solid Struct , 2005,Vol42(14): 58-77.

[23] CHEN Xiao-bin. The stress conditions effects on granular soil's rheological properties in large triaxial rheology laboratory tests, J. Journal of Cent. South University Technology,2008,Vol15(sul):397-401.

DOI: 10.1007/s11771-008-0387-y
