Effect of Minimum Quantity Lubrication to Prediction of Cutting Temperature Distribution in Turning Material AISI-1045

Abstract:

This paper presents a prediction of cutting temperature in turning process, using a continuous cutting model of Johnson-Cook (J-C). An method to predict the temperature distribution in orthogonal cutting is based on the constituent model of various material and the mechanics of their cutting process. In this method, the average temperature at the primary shear zone (PSZ) and the secondary shear zone (SSZ) were determined for various materials, based on a constitutive model and a chip-formation model using measurements of cutting force and chip thicknes. The J-C model constants were taken from Hopkinson pressure bar tests. Cutting conditions, cutting forces and chip thickness were used to predict shear stress. Experimental cutting heat results with the same cutting parameters using the minimum lubrication method (MQL) were recorded through the Testo-871 thermal camera. The thermal distribution results between the two methods has a difference in value, as well as distribution. From the difference, we have analyzed some of the causes, finding the effect of the minimum quantity lubrication parameters on the difference.

• Periodical: Applied Mechanics and Materials (Volume 902)
• Pages: 97-102
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.902.97
• Online since: September 2020
• Authors: Tran Trong Quyet*, Pham Tuan Nghia, Nguyen Thanh Toan, Tran Duc Trong, Luong Hong Sam, Truong Quoc Thanh
• Keywords: Cutting Temperature, Johnson-Cook Constitutive Model, Minimum Quantity Lubrication, Prediction of Cutting Temperature

References

[1] S. Y. L. Jinqiang Ning, Prediction of Temperature Distribution in Orthogonal Machining Based on the Mechanics of the Cutting Process Using a Constitutive Model,, Journal of Manufacturing Material Process, vol. 37, p.15, (2018).

DOI: 10.3390/jmmp2020037

[2] M. K. N.R. Dhar ∗, Mahiuddin Ahmed, Effect of minimum quantity lubrication (MQL) on tool wear and surface roughness in turning AISI-4340 steel,, Journal of Materials Processing Technology vol. 172, (2006).

DOI: 10.1016/j.jmatprotec.2005.09.022

[3] M.M.A. Khan a, M.A.H. Mithu a, N.R. Dhar b, Effects of minimum quantity lubrication on turning AISI 9310 alloy steel using vegetable oil-based cutting fluid,, Journal of Materials Processing Technology, vol. 209, p.11, (2009).

DOI: 10.1016/j.jmatprotec.2009.05.014

[4] D. V. L. a. C. R. Nanavaty, Performance Evaluation of Minimum Quantity Lubrication (MQL) using CBN Tool during Hard Turning of AISI 4340 and its Comparison with Dry and Wet Turning,, Bonfring International Journal of Industrial Engineering and Management Science, (2013).

DOI: 10.9756/bijiems.4392

[5] G. R. a. C. Johnson, W.H., A Constitutive Model and Data for Metals Subjected to Large Strains, High Strain Rates, and High Temperatures,, Proceedings 7th International Symposium on Ballistics, The Hague, vol. 7, p.7, (1983).

[6] J. H. D. S.P.F.C. Jaspersa, Material behaviour in conditions similar to metal cutting: flow stress in the primary shear zone,, Journal of Materials Processing Technology, vol. 122, p.9, (2002).

DOI: 10.1016/s0924-0136(01)01228-6

[7] R. W. Ivester, Kennedy, M., Davies, M., Stevenson, R., Thiele, J., Furness, R., & Athavale, S., ASSESSMENT OF MACHINING MODELS: PROGRESS REPORT,, Machining Science and Technology, vol. 4, p.29, (2000).

DOI: 10.1080/10940340008945720
