Vibration Analysis of Cylindrical with Splitter Plates under Different Deflection Angles at High Reynolds Number

Abstract:

In order to study the influence of the splitter plate in the elastic support system, the SST k-omega turbulence model is used to solve the problem, and the cylindrical system with splitter plate is numerically simulated by overset mesh. This paper studies the effect of the splitter plate on the vibration system at different deflection angles. The results show that the splitter plate has little effect on the system when the deflection angle is low. When the deflection angle is about 10 degrees, the system vibration characteristics will have a sudden change, the amplitude will decrease, and the vortex frequency will increase. Between the deflection angle of 10 degrees and 45 degrees, as the deflection angle increases, the amplitude increases and the vortex frequency decreases. It can be seen from the motion trajectory that the deflection angle changes suddenly after 10 degrees, and the system has a very small amplitude between 10 degrees and 25 degrees. In this declination interval, the splitter plate controls the vibration of the cylindrical system better.

• Periodical: Applied Mechanics and Materials (Volume 904)
• Pages: 51-55
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.904.51
• Online since: January 2022
• Authors: Jun Yan Ding, Cui Xiang Jiang*
• Keywords: Folw-Induced Vibration, High Reynolds Number, Splitter Plate

References

[1] Zhao Jing, Pan Shuchun and Lv Lin. Large eddy simulation of flow past a circle cylinder with splitter plate based on three-step finite element method[J], China Offshore Oil And Gas,2009,21(5):347-351.

[2] Zhang Li and Ding Lin.Research Progress of the Control Technology of the splitter plate for the Flow Around the Blunt Body[J], Advances in Mechanics,2011,41(4):391-399.

[3] Apelt C J,West G S and Szewczy A A. The effects of wake splitter plates on the flow past a circular cylinder in the range 104<Re <5 ×104[J]. Journal of Fluid Mechanics Digital Archive, 1973, 61(1): 187-198.

DOI: 10.1017/s0022112073000649

[4] Zhao Weiwen. Research on numerical methods and applications of vortex-induced motions of column-stabilized floating platforms[D]. Shanghai Jiao Tong University, (2019).

[5] Zhang li and Ding Lin. Effect of Drift Angle of Splitter Plate on Flow Over a Circular Cylinder [J]. Journal of Engineering Thermophysics, 2011(10):1695-1698.

[6] Assi G R S, Bearman P W and Kitney N. Low drag solutions for suppressing vortex-induced vibration of circular cylinders[J]. Journal of Fluids & Structures, 2009, 25(4):666-675.

DOI: 10.1016/j.jfluidstructs.2008.11.002
