Simulation and Uncertainty Analysis of Buckling Behaviour of Thin Cylindrical Shell under Compression

Abstract:

This study analysed the buckling behaviour of thin-cylindrical shells under axial compression, addressing the persistent disparity between theoretical predictions and numerical simulations. The research investigated the influence of key parameters height, Young's modulus, and thickness on the critical buckling load. A Finite Element Analysis (FEA), specifically a Geometrically and Materially Non-Linear Analysis (GMNA), was performed using the software ABAQUS to model the shells. To bridge the gap between simulation and theory, a mathematical model for uncertainty analysis was developed in MATLAB, employing the Monte-Carlo Simulation (MCS) and referencing Rankine's theory. This study introduces a novel analytical framework that integrates Finite Element Analysis (FEA) and uncertainty analysis to resolve discrepancies in buckling predictions for thin cylindrical shells. The model's accuracy was validated with a maximum error of less than 13% compared to existing studies, and the uncertainty analysis demonstrated a robust standard deviation of 0.249 (less than 1%). The findings revealed that thickness is the most influential parameter; a 10% increase in thickness led to a 10.86% increase in the buckling load. Young's modulus had a moderate impact, with a 10% increase causing a 0.28% rise in the buckling load, while height was the least influential, with a 10% increase leading to only a 0.1% increase. This research provides valuable insights into the complexities of predicting critical buckling loads, highlighting the distinct impact of geometric and material properties on the structural behaviour of cylindrical shells.

• Periodical: Applied Mechanics and Materials (Volume 935)
• Pages: 3-10
• DOI: https://doi.org/10.4028/p-RjZGE0
• Online since: April 2026
• Authors: Azizul Hakim Samsudin*, Farhah Nadhirah Md Nordin, Mohd Shahrom Ismail, Ho Quang Nguyen
• Keywords: Buckling, Cylindrical Shell, Finite Element Analysis, Monte Carlo Method, Uncertainty Analysis

References

[1] K. Liang and Z. Li, A Novel and Highly Efficient Strategy to determine the 'Worst' Imperfection Shape for Buckling of Cylindrical Shell panels, Appl. Math. Model., 105 (2022) 631–647.

DOI: 10.1016/j.apm.2022.01.012

[2] S. F. Pitton, S. Ricci, and C. Bisagni, Buckling optimization of variable stiffness cylindrical shells through artificial intelligence techniques, Compos. Struct., 230 (2019) 111513.

DOI: 10.1016/j.compstruct.2019.111513

[3] V. S. Kumar, R. Balamurugan, T. Raja, and B. Saravanan, Experimental investigation on reliable and accurate prediction of buckling analysis of thin cylindrical shells with geometric imperfections, Mater. Today Proc., 45 (2021) 841–851.

DOI: 10.1016/j.matpr.2020.02.914

[4] C. Basaglia, D. Camotim, and N. Silvestre, "GBT-based buckling analysis of steel cylindrical shells under combinations of compression and external pressure," Thin-Walled Struct., 144 (2019) 106274.

DOI: 10.1016/j.tws.2019.106274

[5] M. W. Hilburger, Buckling of thin-walled circular cylinders, NASA/SP-8007 2020/Rev 2, no. August 1968 (2020) 1–60.

[6] J. M. Rotter, Cylindrical shells under axial compression,in Buckling of Thin Metal Structures, no. January 2004, J. T. and J. Rotter, Ed. Spon, London: Research gate, 2003, p.42–87.

DOI: 10.4324/9780203301609_chapter_2

[7] S. K. Kashyap, S. Kumar, M. Mallick, R. P. Singh, and M. Verma, A comparative study between experimental and theoretical buckling load for hollow steel column, Int. J. Eng. Sci. Technol., 10 (2018) 27–33.

DOI: 10.4314/ijest.v10i3.

[8] H. Ma, P. Jiao, H. Li, Z. Cheng, and Z. Chen, Buckling analyses of thin-walled cylindrical shells subjected to multi-region localized axial compression: Experimental and numerical study, Thin-Walled Struct., 183 (2022) 110330.

DOI: 10.1016/j.tws.2022.110330

[9] M. Kusni, H. Syamsudin, L. Gunawan, et al., Optimization of Composite Wing Structure with Static, Buckling, and Flutter Constraints using the Finite Element Method, J. Mech. Eng., 21 (2024) 271–295.

DOI: 10.24191/jmeche.v21i3.27358

[10] M. S. Ismail, J. Mahmud, S. M. Muhammad al-Attas, J. Purbolaksono and J. Błachut, Buckling stability of steel spherical shells: A numerical investigation under combined external pressure, geometric imperfections, and thermal loading, Int. J. of Pressure Vessels and Piping, 218, (2025) 105620.

DOI: 10.1016/j.ijpvp.2025.105620

[11] E. Committee, "The European Union," Eur. Comm. Stand. Com. Eur. Norm. Eur. Kom. FUR NOH. MUNG, vol. 1, 2007.

[12] A. M. Bader, S. T Faris and H. J. M. Al Alkawi Under rotating buckling loading, an evaluation of Euler and ranking buckling theories, Int. J. of Mechanical Eng., 7 (2022) 6597–6603.

[13] M. S. Ismail, S. M. Muhammad al-Attas and J. Mahmud, Buckling behaviour of steel dome cap design under external pressure, Int. J. of Pressure Vessels and Piping, 208 (2024) 105135.

DOI: 10.1016/j.ijpvp.2024.105135

[14] M. Mali, A.H. Samsudin, J. Mahmud, A.K. Hussain and M. Alansary, Failure Analysis of Composite Laminates Under Biaxial Tensile Load Due To Variations in Lamination Scheme, J. of Mechanical Eng., SI 4(5) (2017) 167-182.

[15] O. Ifayefunmi, Buckling behavior of axially compressed cylindrical shells: Comparison of theoretical and experimental data, Thin-Walled Struct., 98 (2016) 558–564.

DOI: 10.1016/j.tws.2015.10.027

[16] S. N. Zahari, M. J. A. Latif, M. S. Zakaria, M. A. Akiah, N. H. Quang and M. R. A. Kadir, Impact of Body Weight on Intervertebral Disc: A Finite Element Analysis of Lumbar Spine Total Disc Replacement, Journal of Mechanical Engineering, 22 (2025) 97-110.

DOI: 10.24191/jmeche.v22i2.6180

[17] H. B. Ly et al., Quantification of uncertainties on the critical buckling load of columns under axial compression with uncertain random materials, Materials 12 (2019) 12111828.

DOI: 10.3390/ma12111828
