Numerical Simulation of SHPB Experiment and Analysis on Stress Wave

Abstract:

Concrete is a typical kind of rate sensitive material. In this paper, the concrete specimens were tested in the SHPB experiment system. Based on H-J-C constitutive model, the SHPB experiment was simulated by LS-DANY. The stress-strain curves which were gat from numerical simulation in the LS-DANY were compared with the stress-strain curves which were gat from SHPB. The results showed that the H-J-C constitutive could simulate the dynamic characteristics of concrete both under room temperature. The result also showed that the concrete was strain rate sensitive. Based on the numerical simulation, the stress wave in the SHPB system was studied. The research of the numerical simulation showed that the stress waves tended to become stable after several oscillations in the incident bar. At the same time, stress wave of elements in r=0 (The distance of elements to the axis was 0) were bigger than the stress wave of r=0.5R (The distance to the axis was 0.5R) and r=R (The distance to the axis was R).

• Periodical: Applied Mechanics and Materials (Volumes 94-96)
• Pages: 397-401
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.94-96.397
• Online since: September 2011
• Authors: Ru Heng Wang, Hua Chuan Yao, Bin Jia, Lin Wang
• Keywords: H-J-C, SHPB, Strain Rate, Stress Wave

References

[1] Zhu Jue, Hu Shi-sheng, Wang Li-li. 2008. "PROBLEMS OF SHPB TECHNIQUE USED FOR RATE-DEPENDENT CONCRETE-SORT MATERIALS,"J.ENGINEERING MECHANICS. Vol.24 No.1

[2] Wang Dao-rong, Hu Shi-sheng. 2003. "Study on damage evolution of concrete under impact load" J.Rock Mechanics andEngineering,2003,22(2):pp.223-226.(in Chinese)

[3] LS-DYNA keyword users's manual, Livermore, California, Livermore Software Technology Corporation (LSTC), 2007.

[4] Johnson G.R.，W.H. Cook, 1983, "A Constitutive Model and Data for Metals Subjected to LargeStrains High Rates and High Temperatures" C. Proceedings of the Seventh International Symposium on Ballistics, The Hague, pp: 541～547.

[5] WangLili, Foundation of stress wave. [M]. Beijing: National Defense Industry
