CFD Numerical Simulation of Internal Flow for Electronic Gasoline Injector

Abstract:

There is increasing demand for a finer atomization of fuel spray in order to improve the engine performance and mileage, reduce exhaust emissions and then improve the transient response. In general, for an engine to comply with this demand, exhaust turbocharger and EGR are necessary especially electronic fuel injection system. As a key part of electronic fuel injection system, the performances of electronic gasoline injector improve the engine power outlet and fuel economy. In other words, electronic gasoline injector can achieve a wonderful dynamic response to improve the combustion process and reduce the exhaust emissions in engine. The aim of this paper is to define a CFD methodology for the simulation of gasoline injector. A two-step work procedure has been adopted. First, three-dimensional computational models of gasoline injector with two kinds of valve seat are created. Then, the simulations are conducted for different geometric parameters of nozzles with properly initialized. The results are used to analysis pressure distribution and the changes of average velocity in the nozzles.

• Periodical: Applied Mechanics and Materials (Volumes 97-98)
• Pages: 745-751
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.97-98.745
• Online since: September 2011
• Authors: Xiao Yan Li, Zhen Dong Zhang, Hao Qian, Qiang Cheng
• Keywords: Computational Fluid Dynamics (CFD), Electronic Gasoline Injector, Internal Flow, Numerical Simulation

References

[1] G. M. Bianchi, F. Brusiani L. Postrioti, C. N. Grimaldi, M. Marcacci, L. Carmignani: SAE Technical paper Series , 2007-24-0041.

DOI: 10.4271/2007-24-0041

[2] Deming Jiang, Changyou Chen, Jialin Yang: Advanced Principles of Automotive Engine. Xi，an, Xi，an Jiaotong University Press(in Chinese), 2006.

[3] Jianqiu Li, Liuqi Zhao, Xiaodong Han: Automotive Electronics Turoial〔M〕. Beijing, Tsinghua University Press(in Chinese), 2006.

[4] Fulin Shen, Yong Zhang: China Journal of Highway and Transport(in Chinese), 2005,18(4): 1152118.

[5] Kegang Wu, Yibin Zhong: Journal of Chang，an University: Natural science Edition(in Chinese), 2004, 24(5) :1112114.

[6] J.M. Nouri, N. Mitroglou, Y. Yan and C. Arcoumanis: London, UK, SAE Technical paper Series, 2007-01-1405.

[7] Reza Rezaei, Stefan Pischinger, Jens Ewald and Philipp Adomeit: FEV Motorentechnik GmbH, SAE paper, 20109037, 2007-01-1405.

[8] M. Pontoppidan and G. Gaviani, G.Bella, A. De Maio: SAE International, 2004-01-0539.

[9] Qi Wang, Xulin Li: Agricultural Equipment and Vehicle Engineering t(in Chinese) 〔J〕, 2007(4).

[10] Minghai Li, Xiaokun Zhang, Hongjiang Cui, Ying Guan: Chinese Internal Combusition Engine Engineering(in Chinese), 2007 8(4).

[11] Binghao Wang, Jianqin Wei, Qiang Li: Transaction of CSICE(in Chinese), 2007(2).
