Analysis of Influence Factors and Rules of Transformer Neutral Point DC

Abstract:

When DC transmission system adopts monopole earth or bipolar imbalance operation mode, the DC grounding electrode will inject large amount of current into the earth, and then disturb the running of the power grid. In view of the influence which is created by DC transmission system in Guangdong power grid, this paper derived the mathematical expressions of the transformer neutral point current after creating a calculation model, and concluded the main influence factors; The subject applied the linear regressing analysis theory to calculate the regression equations of transformers so that the slope of the regressing equation can be used to estimate the influence scope of grounding DC. Finally it concludes that: transformer neutral point current and the power transmitted by DC system has positive correlation; For ±800kV DC Chu Sui, the transformers ,which is more than 80 km away from DC grounding electrode, will no longer be affected; The application of DC suppression devices will affect the neutral point current of the transformers nearby.

• Periodical: Advanced Materials Research (Volumes 1008-1009)
• Pages: 485-492
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1008-1009.485
• Online since: August 2014
• Authors: Xiao Mao Wang, Ying Geng Xie, Yun Zhou, Cheng Jun Xia
• Keywords: DC Blocking Device, Dc Magnetic Bias, Linear Regression, Monopole Ground Operation Mode

References

[1] Shun Yuan, Tianshi Wang: High Voltage Apparatus, Vol. 46(3) (2010), pp.83-87, In Chinese.

[2] Dizheng Kuai, Da Wan, Yun Zou: Electric Power, Vol. 37(8) (2004), pp.41-43, In Chinese.

[3] Yiying Zhu, Weiping Jiang, Zhaohua Zeng: proceeding of the Csee, Vol. 25(13) (2005), pp.1-7, In Chinese.

[4] Rong Zeng, Bo Zhang, Jie Zhao: High Voltage Engineering, Vol. 35(3) (2009), pp.678-682, In Chinese.

[5] Dizheng Kuai, Da Wan, Yun Zou: Automation of Electric Power Systems, Vol. 29(2) (2010), pp.81-82, In Chinese.

[6] P. Picher, L. Bolduc, A. Dutil, et al: IEEE Transactions on Power Delivery, Vol. 12(1)(1997), pp.257-265.

DOI: 10.1109/61.568248

[7] Zhuohong Pan, Lu Zhang: Automation of Electric Power Systems, Vol. 33(20) (2009), pp.88-91, In Chinese.

[8] Jie Zhao, Xiaolin Li: Automation of Electric Power Systems, Vol. 30(12) (2006), pp.88-90, In Chinese.

[9] Chun Shang: High Voltage Engineering, Vol. 30(11) (2004), pp.52-54, In Chinese.

[10] Jiming Lu, Dong Xiao, Chengxiong Mao: High Voltage Engineering, Vol. 32(9)(2006), pp.55-58, In Chinese.

[11] Mingxin Wang, Qiang Zhang: Power System Technology, Vol. 29(3)(2005), pp.9-14, In Chinese.

[12] Léonard Bolduc, Michel Granger, Grégoire Paré, et al: IEEE Transactions on Power Delivery, Vol. 20(1) (2005), pp.163-168.

[13] Liangguang Liu: High Voltage Engineering, Vol. 35(6) (2009), pp.1234-1247, In Chinese.

[14] Rong Zeng, Jie Zhao, Chun Shang: High Voltage Engineering, Vol. 35(4), pp.919-925, In Chinese.

[15] M.A. Eitzmann, R.A. Walling, H. Huynh, et al: IEEE Transactions on Power Delivery, Vol. 7(3)(1992), pp.1328-1337.
