The Study on the Energy Saving of Wall Mounted Solar Capillary Low-Temperature Hot Water Radiant Heating System

Abstract:

Through the comparative study of solar capillary low-temperature hot water radiant heating system with air source heat pump system has found that solar energy heat collecting efficiency has a great relationship with the collector temperature for the given system. To reduce the temperature of solar heat collector circulating water can greatly improve the heat collecting efficiency of the heat collector .With the increase of temperature of the water in the heat collector, heat collecting efficiency decrease rate changes linearly. Increasing water storage can improve the heat collecting efficiency, for this heat collecting system, the optimum collector temperature is 32 °C. In this study, COP reached 5 when the low temperature solar hot water capillary system mode is being used, and this result is nearly 5 times higher than that of the air source heat pump mode . Using the low temperature solar water heating capillary system, 27.35 kwh / (m² ·heating season) of electricity can be saved compared with the amount of electricity consumed by air source heat pump. According to the price of current Beijing city , the estimated period of investment payback is 4.8 years .

• Periodical: Advanced Materials Research (Volumes 1008-1009)
• Pages: 54-57
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1008-1009.54
• Online since: August 2014
• Authors: Xue Jun Li, Xiao Yan Luo, Chuan Qi Xu, Jin Shun Wu, Song Pan*, Zhuo Zhang
• Keywords: Air Source Heat Pump, Capillary, Energy Saving, Radiation Heating, Solar Energy

References

[1] Di Hongfa, Wang Wei, Jiang Yi. Experimental study on [J]. HVAC radiant ceiling, 2000, 30(4): 5-8.

[2] Su duo, Lu Qiongwen. Radiation air conditioning mode and development direction of [J]. refrigeration air conditioning and power machinery, 2005, 24 (93): 26-30.
