Realization of NAND FLASH Control Glueless Interface Circuit

Abstract:

The article realization of NAND FLASH control glueless interface circuit based on FPGA,comparing the advantages and disadvantages of the NAND Flash and analysising the function of control interface circuit. The control interface circuit can correct carry out the SRAM timing-input block erase, page reads, page programming, state read instructions into the required operation sequence of NAND Flash, greatly simplifies the NAND FLASH read and write timing control. According to the ECC algorithm,the realization method of ECC check code generation,error search,error correction is described.The function of operate instructions of the NAND Flash control interface circuit designed in this paper is verified on Xillinx Spartan-3 board, and the frequency can reach 100MHz.
