Two-Phase Stirring Flow Analysis of the Ruston Turbine in Stirred Tank

Abstract:

The effect of the turbine installation position on two-phase flow of a single six-blade ruston turbine in stirred tank with different agitation speeds is numerically simulated by using the large eddy simulation combined with mixture model. The result shows that when stirring low-density mixture, with the increasing stirring axle speed, volume fraction of low-density granules near the paddle is higher, while that near the barrel is low. When the paddle is installed with close distance to the tank bottom, the upper low-density granules are transported to the tank bottom to form good stirring effect. With increasing of the paddle location, distribution of low-density granules is hardly found at the bottom of stirred tank.

• Periodical: Advanced Materials Research (Volumes 1008-1009)
• Pages: 979-982
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1008-1009.979
• Online since: August 2014
• Authors: Xiao Bing Wang*
• Keywords: Large Eddy Simulation, Mixture Model, Multiphase Flow, Ruston Turbine, Stirring

References

[1] H V Hristov, S U Boden, Hampel, et al. Astudy on the two-phase flow in a stirred tank reactor agitated by a gas-inducing turbine [J]. Chemical Engineering Research and Design, 2008, 86: 75-81.

DOI: 10.1016/j.cherd.2007.10.008

[2] Y Chen, H Jiang, Y Y Bao, X B Huang. Turbulence properties of solid-liquid flow in the near-wall region stirred tank [J]. Journal of Chemical Engineering of Japan, 2011, 44(4): 224-232.

DOI: 10.1252/jcej.10we178

[3] E Renaud, L Alain. Analysis of turbulence anisotropy in a mixing tank [J]. Chemical Engineering Science, 2006, 61: 2771-2779.

DOI: 10.1016/j.ces.2005.09.022
