Effect of Bending Speed on Forming Quality of 0Cr21Ni6Mn9N Stainless Steel Tube NC Bending

Abstract:

Based on the nonlinear FE platform ABAQUS, an elastic plastic 3D-FE model of 0Cr21Ni6Mn9N stainless steel tube was established to simulate the whole process, and its reliability was validated by experiment. Using the model, the effect of bending speed on forming quality was studied and the influence laws of bending speed on wrinkling wave ratio, wall thinning, cross section deformation and springback angle were revealed. The results show that the wrinkling wave ratio and springback angle decrease with the increasing of bending speed, while the effect of bending speed on wall thinning and cross section deformation are not significant. The maximum cross section deformation degree presents in the vicinity of the bending angle 30° along the bending direction and its position is almost unchanged with the variation of bending speed.

• Periodical: Advanced Materials Research (Volume 1015)
• Pages: 198-202
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1015.198
• Online since: August 2014
• Authors: Jun Fang*, Shi Qiang Lu, Ke Lu Wang, Zheng Jun Yao
• Keywords: 0Cr21Ni6Mn9N Tube, Bending Speed, Fe Simulation, Forming Quality, NC Bending

References

[1] H. Yang, H. Li, Z.Y. Zhang, M. Zhan, J. Liu and G.J. Li: Chinese J. Aeronaut. Vol. 25(2012), p.1.

[2] J. Yan, H. Yang, M. Zhan and H. Li: Sci. China Tech. Sci. Vol. 53(2010), p.326.

[3] N.C. Tang: Int. J. Pres. Ves. Pip. Vol. 77(2000), p.751.

[4] C. Li, H. Yang, M. Zhan, X.D. Xu and G.J. Li: Trans. Nonferrous Met. Soc. China Vol. 19(2009), p.668.

[5] H. Li, H. Yang, F. F. Song, M. Zhan and G.J. Li: J. Mater. Process. Technol. Vol. 212(2012), p. (1973).

[6] M. Zhan, H.D. Zhai and H. Yang: Trans. Nonferrous Met. Soc. China Vol. 22(2012), p. s287.

[7] H. Yang, H. Li and M. Zhan: J. Mater. Process. Technol. Vol. 210 (2010), p.2273.

[8] J. Fang, S.O. Lu, K.L. Wang, J.M. Xu, X.M. Xu and Z.J. Yao: Adv. Mater. Sci. Eng. Vol. 2013(2013), p.1.
