A Service Restoration Method for Multiple Faults in Distribution Systems Based on Load Balancing Distribution

Abstract:

Current service restoration methods in distribution systems mainly focus on the single fault. When the distribution system deals with more than one fault, current service restoration methods will not be applicable. A service restoration method for multiple faults is proposed to solve the problem mentioned above. Fault outage areas connected through a loop switch compose an unaided fault recovery area which is regarded as a service restoration unit. In order to eliminate the interaction of communal feeders which are connected to more than one unaided fault recovery area, each communal feeder is decoupled into multiple virtual feeders which are assigned to corresponding unaided fault recovery areas based on load balancing distribution. After the process above, the fault recovery area of multiple faults is divided into several independent fault recovery areas and each independent fault recovery area can be restored by traditional service restoration methods. So the contribution of this algorithm is to solve the problem of service restoration of multiple faults. The result of a calculation example proved the validity of the algorithm.

• Periodical: Advanced Materials Research (Volume 1023)
• Pages: 160-167
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1023.160
• Online since: August 2014
• Authors: Guo Fang Zhu*, Hou Lei Gao, Tian You Li
• Keywords: Communal Feeders, Distribution Network, Multiple Faults, Service Restoration

References

[1] Siqing Sheng, Zhirui Liang, Wenqin Zhang, Yihan Yang, Fault restoration of distribution network based on genetic algorithm, Automation of Electric Power Systems, vol. 25, no. 26, pp.53-55, Apr. (2001).

DOI: 10.1109/icpst.1998.728967

[2] Pengxiang Bi, Jian Liu, Chunxin Liu, Wenyuan Zhang, A refined genetic algorithm for power sidtribution network reconfiguration, Automation of Electric Power Systems, vol. 26, no. 2, pp.57-61, Jan. (2002).

DOI: 10.1109/icpst.2002.1067829

[3] Zhigang Lu, Yuxiang Dong. Distribution system restoration based on improved binary particle swarm optimization, Automation of Electric Power Systems, vol. 30, no. 24, pp.39-43, Nov. (2006).

[4] Wei Wei, Xingyuan Li, Ping Liao, Jiao Xu, Qingyun Li, Xin Zhou, A new multi-agent fault restoration method for power system with distribution generations, Automation of Electric Power Systems, vol. 33, no. 3, pp.89-93, Feb. (2009).

[5] Ping Yan, Jinwen Gu, Guang Zhang, A fast efficient service restoration method for distribution network, Automation of Electric Power Systems, pp.52-56, Feb. (2000).

[6] Lan Zheng, Chaohong Bie, Xiuli Wang, A fast heuristic service restoration method for distribution network, Electric Power Automation Equipment，vol. 24, no. 2, pp.16-19, Feb. (2004).

[7] K. N. Miu, H. D. Chiang, B. T. Yuan, D. Gary, Fast service restoration for large-scale distribution systems with priority customers and constraints, IEEE Trans on Power systems, vol. 13, no. 3, pp.789-795, Aug. (1998).

DOI: 10.1109/59.708643

[8] S. Curcic, C. S. Ozveren, K. L. Lo, Computer-based strategy for the restoration problem in electric power distribution systems, " IEE Proc-Generation, Transmission, Distribution, vol. 144, no. 5, pp.389-398, Sep. (1997).

DOI: 10.1049/ip-gtd:19971355

[9] Wenchuan Wu, Boming Zhang, A maydidate restoring tree cutting based algorithm for real-time distribution system restoration, Automation of Electric Power Systems, vol. 27, no. 12, pp.50-54, Jan. (2003).

[10] J. L. Seung, I. L. Seong, S. A. Bok, Service Restoration of Primary Distribution Systems Based on Fuzzy Evaluation of Multi-Criteria, IEEE Trans on Power systems, vol. 13, no. 3, pp.1156-1163, Aug. (1988).

DOI: 10.1109/59.709114

[11] S. I. Lim, S. J. Lee, M. S. Choi, D. J. Lim, Service restoration methodology for multiple fault case in distribution systems, IEEE Trans on Power systems, vol. 21, no. 4, pp.1638-1643, Apr. (2006).

DOI: 10.1109/tpwrs.2006.879275

[12] Qingle Pang, Houlei Gao, Tianyou Li, Load balancing based fault service restoration for smart distribution grid, Power System Technology, vol. 37, no. 2, pp.342-348, Apr. (2013).

DOI: 10.1049/cp.2010.0330
