Stress Analysis of CFRP Externally Pre-Stressed Reinforcement Continuous Beam

Abstract:

An externally pre-stressed continuous box girder bridge is designed according to loading features of the continuous beam. The CFRP bars and steel strands are used to make two models for externally pre-stressed reinforcements at the supporting points. CFRP reinforcement area of Model 1 at the supporting point is 1/2 of steel strand externally pre-stressed reinforcements of model 2 at the supporting points. After the calculation, we can find that under effects of the same tension control stress and the external loads, mechanical effects of the continuous box girder bridges with CFRP bars can be equal to or better than performances of continuous box girder bridges with steel strands. They can provide references to applications of CFRP bar.

• Periodical: Advanced Materials Research (Volume 1028)
• Pages: 300-304
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1028.300
• Online since: September 2014
• Authors: Xin Zhong Wang*, Chuan Xi Li
• Keywords: CFRP, Continuous Beam, External Pre-Stressing, Model

References

[1] Guide for the Design and Construction of Concrete Reinforced With FRP Bars, ACI Committee 440, Revised January (2000).

[2] Qian Rui , Mao Weibin. Investigation and Application for Concrete Specimens Reinforced with FRP Reinforcing Bars in Foreign Countries. Jiangsu Construction Jiangsu Construction, 2001, (1): pp.28-31.

[3] Xue Weichen, Experimental Study on Bonded Prestressed Concrete Beams Reinforced with Fiber Refinforced Plastrics Bars. Industrial Construction 1999, Vol1 29, No12, pp.11-13.

[4] WU Gang, LV Zhitao. The design method of flexural strengthening concrete structure with CFRP. Architectural Construction, 2000, 7: 7-9.

[5] Code for Design of Highway Reinforced Concrete and Prestressed Concrete Bridges and Culverts (JTGD62- 2004). Beijin, China Communications Press, (2004).

[6] ZHANG GuanYong. Bridge structure testing, China Communications Press, 2002. 3.

[7] XU Dong. Design of External Prestressing in Bridges, China Communications Press, 2008. 10.

[8] ZHU Hong , QIAN Yang. Mechanics Performance of FRP Tendons Used in Engineering Structure, Journal of Architecture and Civil Engineering, Vol . 23 No. 3, Sept . 2006, pp.26-31.

[9] DAI WanJiang . Theoretical Research on Behavior of Concrete Beam Reinforced with FRP Bar. Wuhan University of Technology 2007. 11.

[10] YANG Li. Study on the Structural Behaviors of Externally Prestressed ConcreteThree-span Continuous Beams. Souhtwest Jiaotong University, 2005. 4.
