Design and Application of Energy Saving Safety Control Regulator of AC Arc Welding Machine

Abstract:

With the rapid development of our economic in recent year, electricity supply becomes tighter gradually. As when electric welder in ballast, the loss of power is much and factor of power is low which leads to the quality of power supply is poor and accidents of electric shock occurred. In order to solve such prominent problem, we research and the design of energy saving safety control regulator of electric welding machine, it will eliminate the loss of ac welder and improve the quality of power supply, ensuring the safe of the welders. The paper proved the correctness and effectiveness of the design through the installation test at last.

• Periodical: Advanced Materials Research (Volumes 1030-1032)
• Pages: 1592-1595
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1030-1032.1592
• Online since: September 2014
• Authors: Min Wu*, Xiao Gang Xiong
• Keywords: AC Arc Welding Machine, Control Regulator, Energy Security
