Characteristics of Hybrid Coating Deposited by PVD and PACVD Process

Abstract:

Deposited on hot work tool steel substrate coating system composed of AlTiCrN film covered by diamond-like carbon (DLC)-based lubricant, was the subject of the studies. The AlTiCrN and DLC layers were deposited by PVD lateral rotating ARC-cathodes (LARC) and PACVD technology on the X40CrMoV5-1 respectively. This paper provides an analysis of the microstructure, mechanical and tribological properties. Several surface sensitive techniques and methods, i.e. High Resolution Transmission Electron Microscopy (HRTEM), Scanning Electron Microscopy (SEM), Raman spectroscopy and ball-on-disk were used to performed study of the coating. TEM investigation shows an amorphous character of DLC layer. It was found that tested AlTiCrN layer has nanostructural character with fine crystallites. In sliding dry friction conditions the friction coefficient for the investigated elements is set in the range between 0.02-0.04. The investigated coating reveals high wear resistance. The coating demonstrated good adhesion to the substrate.

• Periodical: Advanced Materials Research (Volume 1036)
• Pages: 225-229
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1036.225
• Online since: October 2014
• Authors: Krzysztof Lukaszkowicz*, Justyna Galeja, Agnieszka Paradecka, Paulina Borylo
• Keywords: AlTiCrN Film, DLC Film, HRTEM, SEM, Tribological Properties

References

[1] T. Tanski, K. Lukaszkowicz, Structure and properties of PVD coatings deposited on aluminium alloys, Surface Engineering 28/8 (2012) 598-604.

DOI: 10.1179/1743294412y.0000000033

[2] P. Panjan, P. Gselman, D. Kek-Merl, M. Cekada, M. Panjan, G. Drazic, T. Boncina, F. Zupanic, Growth defect density in PVD hard coatings prepared by different deposition techniques, Surface & Coatings Technology 237 (2013) 349-356.

DOI: 10.1016/j.surfcoat.2013.09.020

[3] F. Vaz, L. Rebouta, M. Andritschky, M.F. da Silva, J.C. Soares, The effect of the addition of Al and Si on the physical and mechanical properties of titanium nitride, Journal of Materials Processing Technology 92-93 (1999) 169-176.

DOI: 10.1016/s0924-0136(99)00159-4

[4] A. Rizzo, L. Mirenghi, M. Massaro, U. Galietti, L. Capodieci, R. Terzi, L. Tapfer, D. Valerini, Improved properties of TiAlN coatings through the multilayer structure, Surface & Coatings Technology 235 (2013) 475-483.

DOI: 10.1016/j.surfcoat.2013.08.006

[5] S. Imamura, H. Fukui, A. Shobata, N. Omori, M. Setoyama, Properties and cutting performance of AlTiCrN/TiSiCM bilayer coatings deposited by cathodic-arc ion plating, Surface & Coatings Technology 202 (2007) 820-825.

DOI: 10.1016/j.surfcoat.2007.05.087

[6] D. Jakubeczyova, P. Hvizdos, M. Selecka, Investigation of thin layers deposited by two PVD techniques on high speed steel produced by powder metallurgy, Applied Surface Science 258 (2012) 5105-5110.

DOI: 10.1016/j.apsusc.2012.01.138

[7] A.P. Carapeto, A.P. Serro, B.M.F. Nunes, M.C.L. Martins, S. Todorovic, M.T. Duarte, V. Andre, R. Colaco, B. Saramago, Characterization of two DLC coatings for joint prosthesis: The role of albumin on the tribological behavior, Surface & Coatings Technology 204 (2010).

DOI: 10.1016/j.surfcoat.2010.04.022

[8] P.L. Wong, F. He, X. Zhou, Interpratation of the hardness of worn DLC particles using micro-Raman spectroscopy, Tribology International 43 (2010) 1806-1810.

DOI: 10.1016/j.triboint.2010.04.008
