Design the Integrated Multipurpose Instrument Calibrating Equipment Based on the PXI and LabVIEW

Abstract:

According to the function, the technical indexes and the cost control etc, we select the embedded control computer and virtual instrument module based on the PXI, and developed the integrated multipurpose instrument calibrating equipment, it realized the field measurement and calibration of the electrical instrument away from the laboratory. The system is designed based on PXI and LabVIEW, it uses virtual instrument technology, automatic control technology and database technology, by combining these functional modules of NI, we realized the calibration of electrical instruments such as digital multimeter, signal generator, oscilloscope and cymometer etc. The system is used integrated design, and it is very flexible, it can be popularized and applied as working standard to troops, factories or schools etc.

• Periodical: Advanced Materials Research (Volume 1037)
• Pages: 134-138
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1037.134
• Online since: October 2014
• Authors: Hai Ming Li*, Li Mei Zhang, Feng Sa
• Keywords: Calibration, Electrical Instrument, LabVIEW, PXI, Virtual Instrument (VI)

References

[1] Wang Y.H. et al. LabVIEW Virtual Instrument Development Platform and Its Analysis of Application. Journal of Liaoning Institute of Technology. 2004, (5): 16-18.

[2] Information on http: /baike. baidu. com/view/5314752. htm.

[3] Information on http: /en. wikipedia. org/wiki/PCI_eXtensions_for_Instrumentation.

[4] National Instruments. NI PXI-8105 product description, (2008).

[5] Yin J.H., F. Wang. The LabVIEW Database Access Technology Based on LabSQL. Instrumentation Technology. 2011, (4): 55-56.

[6] Wu,C.D.,Q.Y. Sun and K. Sheng. Design and Application of Virtual Instrument Program Based on LabVIEW. Beijing: Post &Telecom Press, (2008).
