Paralleling Hydraulic Control of Variable Frequency Motor and Valve for the Swing Mechanism of Segment Erector

Abstract:

Aimed at achieving a high speed and precision circumferential positioning of pipe under low energy consumption, a paralleling hydraulic control of variable frequency motor and valve (PHC-VFMV) system is designed for the swing mechanism of segment erector. Firstly, with a view to the working principle of the swing mechanism, a hydraulic circuit of the PHC-VFMV is designed. Then, two sub-circuits of the hydraulic circuit are separately modeled and equipped with suitable controllers. Finally, one valve control (VC) system and the designed PHC-VFMV system are tested in AMEsim platform. Results show that, while guaranteeing a good performance of speed and accuracy, the PHC-VFMV could achieve a better performance in energy saving than VC.

• Periodical: Advanced Materials Research (Volume 1037)
• Pages: 264-269
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1037.264
• Online since: October 2014
• Authors: Xu Yang, Guo Fang Gong*, Wei Qiang Wu, Yun Yi Rao
• Keywords: Circumferential Positioning, Energy Consumption, PHC-VFMV, Precision, Speed

References

[1] Li, Y., Zhang, X. T., Bai, T. G., 2013, Research of the segment block and the thrust cylinders of sheld machine , Construction Mechanization, Vol. 11, pp.65-68.

[2] Braaksma, J., Klaassens, B., Babuska, R., 2006, Hybrid control design for a robot manipulator in a shield tunneling machine, Informatics in Control, Automation and Robotics I, pp.143-150.

DOI: 10.1007/1-4020-4543-3_17

[3] Kosuge, K., Takeo, K., Taguchi, D., et al, 1996, Task-oriented force control of parallel link robot for the assembly of segments of a shield tunnel excavation system, IEEE/ASME Transactions on Mechatronics, Vol. 1, No. 3, pp.250-258.

DOI: 10.1109/3516.537048

[4] YAO, Y.G., ZHAO, J,Y., 2005, Development and Research Overview of AC Variable Frequency Hydraulic Speed Regulation System , Chinese Hydraulics & Pneumatics, Vol. 11, pp.37-40.

[5] Nordhammer, P.A., Bak, M.K., Hansen, M.R., 2012, A Method for Reliable Motion Control of Pressure Compensated Hydraulic Actuation With Counterbalance Valves, 12th International Conference on Control, Automation and Systems, pp.759-763.

[6] Wang, Z.P., Hu, J.K., Yang, W.B., et al, 2013, Research on the stability of boom luffing mechanism at decline stage, Journal of Hefei University of Technology (Natural Science), Vol. 36, No. 7, 783-787, 815.

[7] Chen, Y.L., Liu, S.A., Shang, T., et al, 2011, Braking energy regenerative efficiency of hydraulic hybrid vehicle, Journal of Jilin University (Engineering and Technology Edition), Vol. 41, No. 1, pp.110-116.
