Active Infrared Thermography for Defect Detection of Polyethylene Pipes

Abstract:

We present defect detection of polyethylene (PE) pipes by using active infrared thermography technique. A finite element model was built to mimic the transient heat transfer in PE pipes, in which constant heat flux boundary condition was applied to the inner surface of the PE pipes. Various defects with different diameters and depths were simulated in PE pipes and they would affect the thermal distributions from which the relation between thermal images and defect sizes and locations would be established. An electrical heating bar, as the novel thermal excitation source, was employed in active infrared thermography experimental system. The finite element simulation results are well agreed with the one obtained from the infrared imaging experiments and it demonstrated that finite element numerical method can be an effective method to analyze infrared imaging. Furthermore, defects in heat fusion joints of PE pipes were fabricated and detected by the developed active infrared thermography. The experiment showed that active infrared thermography based on an electrical heating bar could provide a novel tool for nondestructive evaluation of PE pipes.

• Periodical: Advanced Materials Research (Volumes 1044-1045)
• Pages: 700-703
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1044-1045.700
• Online since: October 2014
• Authors: Zhi Bin Zhu, Xu Qiu, Shun Cong Zhong*, Xi Bin Fu, Xiao Xiang Yang
• Keywords: Active Infrared Thermography, Defect Detection, Defective Polyethylene Pipes, Thermal Excitation

References

[1] Chris O'Connor, GL Noble Denton, The Nature of Polyethylene Pipe Failure. Pipeline & Gas Journal, 2012: 76-77.

[2] D. S. Caravaca, C. Bird and D. Kleiner, Ultrasonic phased array inspection of electrofusion joints in polyethylene pipes, Insight, 49(2007): 83-86.

DOI: 10.1784/insi.2007.49.2.83

[3] Jinyang Zheng, Jianfeng Shi, Weican Guo. Development of NondestructiveTest and Safety Assessment of Electrofusion Joints for Connecting Polyethylene Pipes. Pressure Vessel Technology, 134(2012): 021406-1 - 021406-5.

DOI: 10.1115/1.4004869

[4] Jianfeng Shi, Jinyang Zheng, Weican Guo, Ping Xu, Yongquan Qin, Shangzhi Zuo. A Model for Predicting Temperature of Electrofusion Joints for Polyethylene Pipes. Pressure Vessel Technology, ASME, 131(2009): 061403-1 – 061403-8.

DOI: 10.1115/1.4000202

[5] Caleb Frederick Allen Porter, David Zimmerman. High-Density Polyethylene Piping Butt-Fusion Joint Examination Using Ultrasonic Phased Array. Proceedings of the 17th International Conference on Nuclear Engineering, July, 2009: 1-5.

DOI: 10.1115/pvp2009-77783

[6] T. W. Kirby, Capacitive sensor technology for polyethylene pipe fault detection, MSc thesis, West Virginia University, (2009).

[7] M. Pal, N. Dixon and J. Flint, Detecting & locating leaks in water distribution polyethylene pipes, Proceedings of the world congress on engineering, 2010 Vol II.

[8] R. Stakenborghs, and J. Little, Microwave based NDE inspection of HDPE fusions, Proceedings of the 17th International Conference on Nuclear Engineeirng, July 2009, ICONE17-75742.

[9] C. Jördens, N. Krumbholz, B. Baudrit, M. Bastian and M. Koch, Terahertz imaging: a new non-destructive technique for the quality control of plastic weld joints, Journal of the European Optical Society, 2(2007): 07013- 1 - 07013- 5.

DOI: 10.2971/jeos.2007.07013

[10] G. M. Carlomagno, Application of infrared thermography to adhesion science, Journal of Adhesion Science and Technology, 20 (2006): 589-632.

DOI: 10.1163/156856106777412491
