Agricultural Robot Localization Based on Camera Ranging

Abstract:

In this paper, a camera ranging method for agricultural robot localization in arable farming is described. Three calibration objects in different directions in the field are set. The distances between the robot are calculated, and the calibration objects are used the camera to obtain the robot position. The benchmarking procedure in Matlab includes image binarization of the calibration object and the curve fitting method was used to establish the relationship between the pixels number of the calibration object and the actual distance. The verification results show that the relative error of ranging is less than 1.5%. Furthermore, the camera ranging method for agricultural robot localization is proved to be easy and feasible.

• Periodical: Advanced Materials Research (Volumes 1044-1045)
• Pages: 704-707
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1044-1045.704
• Online since: October 2014
• Authors: Ke Wang*, Zhen Yang Ge, Ying Jie Yu, Wang Wang Wu
• Keywords: Agricultural Robot, Camera Ranging, Curve Fitting, Field Localization, Image Binarization, Pixel Number

References

[1] QinLao Y, Chi G, GuangXing Z, et al. Double three-point fix and objective diagram fitting controlling of farming robot [J]. Transactions of the Chinese Society for Agricultural Machinery, 2009, 40(9): 171-174.

[2] Mouaddib E M, Marhic B. Geometrical matching for mobile robot localization[J]. Robotics and Automation, IEEE Transactions on, 2000, 16(5): 542-552.

DOI: 10.1109/70.880804

[3] Hanek R, Schmitt T. Vision-based localization and data fusion in a system of cooperating mobile robots[C]/Intelligent Robots and Systems, 2000. (IROS 2000). Proceedings. 2000 IEEE/RSJ International Conference on. IEEE, 2000, 2: 1199-1204.

DOI: 10.1109/iros.2000.893182

[4] LIU Y, GAO J, CHEN Y, et al. A Simple Method of Computer Vision Localization[J]. Manufacture Information Engineering of China, 2009, 11: 012.
