A Novel Structural Design of Heat-Dissipation Method for High Brightness LED Lighting with Thermoelectric Chip Module

Abstract:

In various traditional technologies of solving the heat-dissipation problem for LED, all of these methods exhaust the waste heat into the environment and cause the more serious greenhouse effect. In this article, we present a new heat-dissipation method for high brightness 10W LED bulb using a novel structure of thermoelectric chip module. Evidence illustrates that graphite performs both the best heat-absorption material as well as the superior heat-dissipation material for LED thermoelectric chip module. Besides, the double-layered structure with graphite as heat-conduction material of LED thermoelectric module could create the most temperature-difference and thus conduct the highest output power. It implies that double-layered structure of LED thermoelectric chip module with graphite as heat-conduction material is the optimal structure for heat-dissipation of 10W LED bulb.

• Periodical: Advanced Materials Research (Volume 1051)
• Pages: 823-827
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1051.823
• Online since: October 2014
• Authors: Ching Wu Wang*, Ti Chun Yeh, Kai Chun Lin, Kuan Hsun Chen, Wei Chih Wang, Po Kai Lin, Chien Hua Chen, Ta Yu Chiu, Chih Wei Wu
• Keywords: Green House Effect, Heat-Dissipation, LED Lighting, Thermoelectric Chip Module

References

[1] Yoon and J.W. Park, The thermal resistance of solder joints in high brightness light emitting diode (HB LED) packages, IEEE Transactions on Components and Packaging Technologies, Vol. 32, pp.825-831 (2009).

DOI: 10.1109/tcapt.2009.2033414

[2] T. Tanaka, K. Hayashida, K. Saito, M. Nishio, Q. Guo, and H. Ogawa, Effect of surface treatment on properties of ZnTe LED fabricated by Al thermal diffusion, Physica Status Solidi B-Basic Solid State Physics, Vol. 243, pp.959-962 (2006).

DOI: 10.1002/pssb.200564729

[3] K.S. Vandewalle, H.W. Roberts, A. Tiba, and D.G. Charlton, Thermal emission and curing efficiency of LED and halogen curing lights, Operative Dentistry, Vol. 30, pp.257-264 (2005).

DOI: 10.1016/s0084-3717(08)70037-0

[4] S.B. Riffat, S.A. Omer, and X.L. Ma, A novel thermoelectric refrigeration system employing heat pipes and a phase change material: an experimental investigation, Renewable Energy, Vol. 23, pp.313-323 (2001).

DOI: 10.1016/s0960-1481(00)00170-1

[5] U. Ghoshal, S. Ghoshal, C. McDowell, L. Shi, S. Cordes, and M. Farinelli, Enhanced thermoelectric cooling at cold junction interfaces, Applied Physics Letters, Vol. 80, p.3006 (2002).

DOI: 10.1063/1.1473233

[6] E. Vremera, L. Brunetti, L. Oberto, and M. Sellone, Alternative procedures in realizing of the high frequency power standards with microcalorimeter and thermoelectric power sensors, Measurement, Vol. 42, pp.269-276 (2009).

DOI: 10.1016/j.measurement.2008.06.010

[7] K. Fukutani and A. Shakouri, Design of bulk thermoelectric modules for integrated circuit thermal management, IEEE Transactions on Components and Packaging Technologies, Vol. 29, pp.243-247 (2006).

DOI: 10.1109/tcapt.2006.885938

[8] O. Yamashita and H. Odahara, Current conduction and saturation mechanism in AlGaN/GaN ungated structures, J. Appl. Phys., Vol. 99, p.123721 (2006).
