A Measurement Based on Tunable Diode Laser Absorption Spectroscopy for Pressure in Gas Flow

Abstract:

Pressure is a very important parameter for combustion diagnostics since pressure is a good indicator of combustion efficiency .As combustion technologies mature, more accurate and less response time pressure diagnosis are needed. Line of sight (LOS) tunable diode laser absorption spectroscopy (TDLAS) provides a fast, nonintrusive, sensitive and reliable solution for quantitative sensing of multiple flow field parameters including gas temperature, components concentration, and mass flux. So far, there is no mature method to measure gas pressure using TDLAS, and it is very important to perfect TDLAS measuring system with the gain of pressure.This paper intends to found a method based on TDLAS for gas pressure measurement. At first, a gas pressure measuring method is presented. Then, an experiment is conducted in a heated static cell to verify this method. A Direct-Absorption-Based Senor which scans H₂O transitions near 1.4 μm was used, and this made the measuring system compact, low cost, simple to operate and quick to response. The experiment successfully measured the pressure in several pressure points, and the results agreed well with the data measured by pressure sensor, average difference is 3.1%.

• Periodical: Advanced Materials Research (Volume 1051)
• Pages: 910-914
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1051.910
• Online since: October 2014
• Authors: Song Ji Peng, Yan Ji Hong, Guang Yu Wang, Hu Pan
• Keywords: Absorption Spectroscopy, Direct-Absorption-Based Senor, Pressure Measurement, Tunable Diode Laser

References

[1] Williams J G, Steenken W G, Yuhas A J. Estimating engine air-flow in gas-turbine powered aircraft with clean and distorted inlet flows[R]. NASA CR-198052, (1996).

[2] Li H. Near-infrared Laser Absorption Spectroscopy with Applications to Reactive Systems and Combustion Control[D]. PhDStanford University, (2007).

[3] Sun K. Utilization of Multiple Harmonics ofWavelength Modulation Absorption Spectroscopy for Practical Gas Sensing[D]. PhDStanford University, (2013).

[4] Brown M S and Barhorst T F. Post-flight analysis of the diode-laser-based mass capture experiment onboard HIFiRE Flight 1[C]. 17th AIAA International Space Planes and Hypersonic Systems and Technologies Conference, (2011).

DOI: 10.2514/6.2011-2359

[5] Jackson K R, Gruber M R. The HIFiRE flight 2 overview and status update 2011[R]. AIAA 2001-2202.

[6] Michael S, Skip, et al. Progress in Applying Tunable Diode Laser Absorption Spectroscopy to Scramjet Isolators and Combustions[R]. Wright-Patterson Air Force Base, Aerospace Propulsion Division, (2010).

[7] Zhou X, Liu X, Jeffries J B, et al. Development of a Sensor for Temperature and Water Concentration in Combustion Gases Using a Single Tunable Diode Laser[J]. Meas. Sci. Technol., Vol. 14, (2003).

DOI: 10.1088/0957-0233/14/8/335

[8] Sun K. Utilization of Multiple Harmonics of Wavelength Modulation Absorption Spectroscopy for Practical Gas Sensing [D]. PhD Stanford University, (2013).
