Effects of Stoichiometric Ratio on the Microstructure and Electrochemical Properties of Ml_0.96Mg_0.04(Ni_0.846Co_0.014Mn_0.08Al_0.06)_x (x=5.0-5.3) Alloys

Abstract:

The as-cast Ml_0.96Mg_0.04(Ni_0.846Co_0.014Mn_0.08Al_0.06)_x (x=5.0, 5.1, 5.2, 5.3) hydrogen storage alloys were prepared by vacuum induction melting method under argon atmosphere. Crystal structure, hydrogen absorption, desorption properties and electrochemical properties were investigated by means of XRD, SEM, EDS, PCT (Pressure Composition isotherms) and tri-electrode tests. The XRD and SEM results showed that the alloy were consisted of CaCu₅-type phase as the main phase and (Al, Mn)(Ni, Co)₂-type phase as the secondary phase. The content of the second phase increased as the stoichiometric ratio increased. PCT results indicated that the amount of hydrogen absorption decreased, while the hydrogen-desorption plateau pressure increased as the stoichiometric ratio increased. The electrochemical test results exhibited that the alloys had excellent activation performance at the second cycle, and the maximum capacity of the alloys were 341.2 mAh/g, 336.5 mAh/g, 333.6 mAh/g, 330.3 mAh/g as the stoichiometric x=5.0, 5.1, 5.2, 5.3, respectively. In addition, the cycle life increased slightly as the stoichiometric ratio increased. ML_0.96Mg_0.04(Ni_0.846Co_0.014Mn_0.08Al_0.06)_5.0 had the best performance due to the combine action of trace Mg and stoichiometric ratio.

• Periodical: Advanced Materials Research (Volume 1053)
• Pages: 87-92
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1053.87
• Online since: October 2014
• Authors: Hui Guo*
• Keywords: Electrochemical Property, Hydrogen Storage Alloys, Phase Structure, Pressure-Composition-Isotherms

References

[1] S. Yang, S. Han, J.Z. Song, Y. Li. Influences of molybdenum substitution for cobalt on the phase structure and electrochemical kinetic properties of AB5-type hydrogen storage alloys. Journal of Rare Earth, 2011, 29(7): 692.

DOI: 10.1016/s1002-0721(10)60524-8

[2] S. Bliznakov, E. Lefterova, N. Dimitrov, K. Petrov, A. Popov. A study of the Al content impact on the properties of MmNi4. 4−xCo0. 6Alx alloys as precursors for negative electrodes in NiMH batteries. Journal of Power Sources, 2008, 176(1): 381.

DOI: 10.1016/j.jpowsour.2007.10.028

[3] Yanping Fan，Baozhong Liu, Baoqing Zhang, Liqiang Ji, Yongguang Wang, Zhi Zhang. Microstructures and electrochemical properties of LaNi3. 55Co0. 2-xMn0. 35Al0. 15Cu0. 75(Fe0. 43B0. 57)x (x = 0-0. 20) hydrogen storage alloys. Materials Chemistry and Physics, 2013, 138: 803.

DOI: 10.1016/j.matchemphys.2013.01.001

[4] Shuqin YANG, Shumin HAN, Jianzheng SONG, Yuan LI. Influences of molybdenum substitution for cobalt on the phase structure and electrochemical kinetic properties of AB5-type hydrogen storage alloys. Journal of Rare Earth, 2011, 29(7) : 692.

DOI: 10.1016/s1002-0721(10)60524-8

[5] W.K. Hu. Studies on cobalt-free AB5-type hydrogen storage alloys. Journal of Alloys and Compounds, 1999, 289(1-2): 299.

DOI: 10.1016/s0925-8388(99)00185-1

[6] A. Z¨uttel, D. Chartouni, K. Gross, P. Spatz, M. B¨achler, F. Lichtenberg,A. F¨olzer, N.J.E. Adkins. Relationship between composition, volume expansion and cyclic stability of AB5-type metalhydride electrodes. Journal of Alloys and Compounds. 1997, 253–254 (20): 626.

DOI: 10.1016/s0925-8388(96)02976-3

[7] M Zhu, Y Gao, X. Z Che, Y. Q Yang, C. Y Chung. Hydriding kinetics of nano-phase composite hydrogen storage alloys prepared by mechanical alloying of Mg and MmNi5−x(CoAlMn)x. Journal of Alloys and Compounds. 2002, 330-332(17): 708.

DOI: 10.1016/s0925-8388(01)01517-1

[8] Peng Zhang, Xuedong Wei, Yongning Liu, Jiewu Zhu, Zhanling Zhang, Tingkai Zhao. The microstructures and electrochemical properties of non-stoichiometric low-Co AB5 alloys containing small amounts of Mg. Journal of Alloys and Compounds, 2005, 399(1-2) : 270–275.

DOI: 10.1016/j.jallcom.2005.03.040

[9] S.L. Li, P. Wang, W. Chen, G. Luo, D.M. Chen, K. Yang, Effect of non-stoichiometry on hydrogen storage properties of La(Ni3. 8Al1. 0Mn0. 2)x alloys. International Journal of Hydrogen Energy 2010, 35(8): 3537.

DOI: 10.1016/j.ijhydene.2010.01.102

[10] P.H. L. Notten, R.E.F. Einerhand, J.L.C. Daams. On the nature of the electrochemical cycling stability of non-stoichiometric LaNi5-based hydride-forming compounds Part I. crystallography and electrochemistry. Journal of Alloys and Compounds. 1994, 210(1-2)221.

DOI: 10.1016/0925-8388(94)90142-2

[11] P.H. L. Notten, J.L.C. Daams, R.E.F. Einerhand, On the nature of the electrochemical cycling stability of non-stoichiometric LaNi5-based hydride-forming compounds Part II. In situ x-ray diffractometry. Journal of Alloys and Compounds. 1994, 210(1-2): 233.

DOI: 10.1016/0925-8388(94)90143-0

[12] N. Higashiyama, Y. Matsuura, H. Nakamura, M. Kimoto, M. Nogami, I. Yonezu, K. Nishio. Influence of preparation methods of non-stoichiometric hydrogen-absorbing alloys on the performance of nickel-metal hydride secondary batteries. Journal of Alloys and Compounds, 1997, 253-254(20): 648.

DOI: 10.1016/s0925-8388(96)03076-9
