PID Control of a Parallel Vibration Isolation System Based on Pneumatic Artificial Muscle

Abstract:

In the ultra precision measuring and machining, precision measuring instruments and precision accuracy are not only related to the precision of the instrument itself, the vibration from the surrounding environment, and many other factors also determine the accuracy of the measurement and processing. In order to solve the micro-amplitude vibration and shock proof problem of high precision equipment, the article adopted the active vibration isolation technology to build the vibration isolation experiment system based on the pneumatic artificial muscle as the action, according to the characteristics of the vibration isolation system and performance requirements, The experiment was completed by using PID control algorithm. By comparing with passive control, the results show that the vibration isolation system has good broadband vibration isolation effect, in the low frequency, effect is remarkable. This study laid a foundation for further control of pneumatic muscle in isolation system.

• Periodical: Advanced Materials Research (Volumes 1061-1062)
• Pages: 899-903
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1061-1062.899
• Online since: December 2014
• Authors: Yan Bin Liu*, Jia Jia Ma, Chen Xu Yin
• Keywords: Active Control, Isolation, PID Control, Pneumatic Muscle

References

[1] Lee J H, Kim K J. Journal of Sound and Vibration, 2009, 323(1): 67-92.

[2] Shimozawa K, TohtakE T. Quarterly Report of RTRI, 2008, 49(4): 209-214.

[3] Dagang Sun, Chenxi Feng, Yong Song, Xin Zhang, Nanyan Lu. Journal of Green Science and Technology. 2011: 146-150. (In Chinese).

[4] Bishi Ren, Guanglin Shi. MACHINE TOOL AND HYDRAULICS. 2010: 85-90. (In Chinese).

[5] Gang Yang, Baoren Li, Xiaoyun Fu. China Mechanical Engineering. Vol 17, Issue 12(2006), (In Chinese).

[6] Situm Z, Herceg S Design and Control of a Manipulator Arm Driven by Pneumatic Muscles Actuators NO. 4602136.

DOI: 10.1109/med.2008.4602136

[7] Wang Y T, Wong R H, Yu C W Fuzzy control: 2D pneumatic muscle actuator's arm 2009(01).

[8] Sifu Li. Basis of computer control (University of Science and Technology of China Press, Hefei, China2001).
