Blank Shape Sensitivity on Temperature Distribution of Hot Stamping Boron Steel through Conduction Heating

Abstract:

The conduction heating overcomes shortage of the radiation heating because of rapid heating and high energy efficiency. It is suitable for heating of blanks with an appropriate length/width ratio. In this study, a conduction heating system was developed in terms of Joule’s Law. Sensitivity of blank shapes on temperature distribution of hot stamping boron steel during conduction heating was investigated. Heating experiments of boron steel blanks with irregular-shapes, such as ladder, joist and rectangle with variable cross-section were implemented on the system. The results showed that the steady temperature was decided by the shape of the blanks. It was indicated that the steady temperature of the tested blanks was inversely proportion to the sectional area.

• Periodical: Advanced Materials Research (Volume 1063)
• Pages: 211-214
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1063.211
• Online since: December 2014
• Authors: Wei Kang Liang, Liang Wang, Yong Liu, Yi Lin Wang, Yi Sheng Zhang*
• Keywords: Blank Shape, Conduction Heating, Temperature Distribution, Temperature Rising Rate

References

[1] C. Wang, Y.S. Zhang, Y.W. Tian, B. Zhu, J. LI, Thermal contact conductance estimation and experimental validation in hot stamping process, Science China-Technological. 55 (2012) 1852-1857.

DOI: 10.1007/s11431-012-4871-0

[2] Z.X. Gui, Y.S. Zhang, H.Q. Li, M.T. Ma, Hot stamping and blank designing for a vehicle bumper using ultra high strength steel (UHSS), Advanced Materials Research. 690-693 (2013) 2240-2244.

DOI: 10.4028/www.scientific.net/amr.690-693.2240

[3] H. Karbasian, A. E. Tekkaya, A review on hot stamping, J. Mater. Process. Technol. 210 (2010) 2103-2118.

DOI: 10.1016/j.jmatprotec.2010.07.019

[4] J. Schonbeck, H. -J. PerIwitz: Induktives Erwarmen in ISP-Anlagen, elektrowarme international, Heft B2, Juni 2008. pp.48-55.

[5] R. Kolleck, R. Veit, M. Merklein, J. Lechler, M. Geiger, Investigation on induction heating for hot stamping of boron alloyed steels, CIRP Ann-Manuf. Tech. 58 (2009) 275-278.

DOI: 10.1016/j.cirp.2009.03.090

[6] K. Mori, S. Maki, Y. Tanaka, Warm and Hot Stamping of Ultra High Tensile Strength Steel Sheets Using Resistance Heating, CIRP Ann-Manuf. Tech. 54(2005) 209-212.

DOI: 10.1016/s0007-8506(07)60085-7

[7] K. Mori, S. Saito, S. Maki, Warm and hot punching of ultra high strength steel sheet, CIRP Ann-Manuf. Tech. 57 (2008) 321–324.

DOI: 10.1016/j.cirp.2008.03.125

[8] K. Mori, T. Maeno, K. Mongkolkaji, Tailored die quenching of steel parts having strength distribution using bypass resistance heating in hot stamping, J. Mater. Process. Technol. 213 (2013) 508-514.

DOI: 10.1016/j.jmatprotec.2012.10.005

[9] Z.X. Men, J. Zhou, M.H. Wang, C.W. Shao, Development and experiments of direct resistance heating in hot forging, Journal of Chongqing University. 34 (2011) 67-72. In chinese.

[10] W.K. Liang, M.L. Zhou, H.Q. Liu, Y.S. Zhang, Experimental study on conduction heating of ultra-high strength boron steel, Advanced Materials Research, 898 (2014) 185-188.

DOI: 10.4028/www.scientific.net/amr.898.185
