Structural Finite Element Analysis of Tower Top of Landing-Type Lifting Pole with Double-Level Arms

Abstract:

The landing-type lifting pole with double-level arms is a kind of construction equipment frequently used in erection of large-sized iron tower during the engineering of power transmission line. This equipment lifts heavy load through bilateral symmetry, thus improving the working efficiency. A finite element structural calculation model of tower top of landing-type lifting pole with double-level arms was established according to the actual situation, and this model involved different working amplitude, lifting capacities and unbalanced loading conditions. In addition, the maximum stresses and structural stability coefficients of tower head, lifting arm, draw-bar and rotary tower body were analyzed, and the safety check results of various parts at tower top were obtained. Finally, the design of connection pin of each part at tower top of lifting pole was also proposed.

You might also be interested in these eBooks

Civil, Structural and Environmental Engineering III

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 1065-1069)

Pages:

1121-1124

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.1121

Citation:

Cite this paper

Online since:

December 2014

Authors:

Jian Qin*, Jie Su, Yong Jun Xia, Hong Sheng Zhang, Jin Miao Zhang, Yu Jing Hao

Keywords:

Double-Level Arms, Finite Element, Lifting Pole, Structural Analysis, Tower Top

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Li Qingjiang, Lin Guanglong, Liu Haixiang. Application of double horizontal rotating and lifting arm grounding hold-poles in construction of large crossing towers. Guangdong Electric Power, 11(2011), pp.72-76.

Google Scholar

[2] Ye Jianyun, Huang Chaosheng, Duan Fuping. A structure pattern of derrick with double level arm rotating pole and Application. Engineering and Construction. 23(2009), 3, pp.399-401.

Google Scholar

[3] Xu Yongtao, Song Lianyu. Research on Tower Crane Load Deviation. Modern Manufacturing Technology and Equipment. 3(2013). pp.18-19.

Google Scholar

[4] Bai Jinze, Sun Qin, Guo Yingnan, Stress-analysis of a Complex Structure with the ANASYS System, Mechanical Science and Technology. 22(2003), 3, pp.441-444.

Google Scholar
