Simulation of a Cantilevered Thin-Elastic Plate with Large Deformation Subjected to Axial Flow

Abstract:

The instability and dynamics behavior of a cantilevered thin-elastic plate with large deformation subjected to axial flow is studied numerically. The structural dynamics equation is discretized by isoparametric displacement-based finite, and the motion of a continuous fluid domain is governed by two-dimensional incompressible viscous Navier-Stokes equations, which discretized by finite volume method. The two-dimensional numerical model of two-way fluid-structure coupling is established combined with moving mesh technology, realizing the interaction of thin-elastic plate and axial fluid. Firstly, under given different flow velocity, the stability of limit-cycle oscillations has been studied through Hopf bifurcation, time trace, vibration responses. Secondly, the fluid domain features are analyzed qualitatively by separately comparing with vorticity under given different flow velocity, and cloud diagram of pressure and velocity are also analyzed at U=3.6m/s.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 2069-2075
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.2069
• Online since: December 2014
• Authors: Wei Bin Hong*, Chang Qing Guo, Ye Zhou Sheng
• Keywords: Fluid Domain Features, Large Deformation, Oscillation, Thin Elastic Plate, Two-Way Fluid-Structure Coupling

References

[1] Xingjing Tang, Sheng Zhou, Cui E J. A survey on the fluid-solid interaction mechanics (In Chinese). Advances in Mechanics, 1997, 27(1): 19-38.

[2] Païdoussis M P. Fluid-structure interactions: Slender structure and Axial Flow [M]. London: Elsevier Academic Press, 2004, 2.

[3] Dowell E H. Aeroelasticity of Plate and Shells [M]. Leyden: Noordho International Publishing, (1975).

[4] Guo C Q, Païdoussis M P. Stability of rectangular plates with free side-edges in two-dimensional inviscid channel flow [J]. Journal of Applied Mechanics, 2000, 67: 171-176.

DOI: 10.1115/1.321143

[5] Guiqing Chen, Yiren Yong. Study on flow induced vibration for a plate-tyoe beam structure with nonlinear support (In Chinese ) [J]. Chinese Journal of solid Mechanics, 2003, 24(3): 277-283.

[6] Zhao W S, Païdoussis M P. Theoretical and experimental investigations of the dynamics of cantilevered flexible plates subjected to axial flow [J]. Journal of Sound and Vibration, 2012, 331: 575-587.

DOI: 10.1016/j.jsv.2011.08.014

[7] Tang L S, Païdoussis M P. On the instability and the post-critical behavior of two-dimensional cantilevered flexible plates in axial. Journal of Sound and Vibration, 2007, 305(1): 97-115.

DOI: 10.1016/j.jsv.2007.03.042

[8] Huang L. Flutter of Cantilevered Plates in Axial-Flow. Journal of Fluids and Structures, 1995, 9(2): 127-147.

DOI: 10.1006/jfls.1995.1007

[9] Yamaguchi N, Yokota K, Tsujimoto Y. Flutter limits and behaviors of a flexible thin sheet in High-Speed Flow. Journal of Fluids Engineering, 2000, 122(1): 65-83.

DOI: 10.1115/1.483242

[10] Watanabe Y, Suzuki S, Sugihara M, et al. An experimental study of paper flutter. Journal of Fluids and Structures, 2002, 16(4): 529-542.

DOI: 10.1006/jfls.2001.0435

[11] Watanabe Y, Isogai K, Suzuki S, et al. A Theoretical study of paper flutter. Journal of Fluids and Structures, 2002, 16(4): 543-560.

DOI: 10.1006/jfls.2001.0436

[12] Zhang J, Childress S, Libchaber A, et al. Flexible filaments in a flowing soap film as a model for one-dimensional flags in a two-dimensional wind. Nature, 2000, 408(6816): 835-839.

DOI: 10.1038/35048530

[13] Fitt A D, Pope M P. The unsteady motion of two-dimensional flags with bending stiffness. Journal of Engineering Mathematics, 2001, 40(3): 227-248.

[14] Farnell D J J, David T, Barton D C. Coupled states of flapping flags. Journal of Fluids and Structures, 2004, 19 (1): 29-36.

DOI: 10.1016/j.jfluidstructs.2003.10.001

[15] Zhiyuan Cheng, Li Li. Research on the application of moving mesh technology in computational fluid dynamics simulation(In Chinese). Journal of Chongqing University, 2013, 36(2): 96-101.
