Site Test and Analysis of Vibration Attenuation Effect of Steel Spring Floating Slab Track

Abstract:

Through site test, the paper conducts site test to vertical vibration accelerations when a train passes through steel rails and tunnel walls at a steel spring floating slab track section and a general track section in the tunnel of Yizhuang Line of Beijing Metro. The paper also conducts comparative analysis of the accelerations in time domain and frequency domain. It is shown in results that the vibration acceleration level of the steel spring floating slab track in time domain is reduced by 22 dB in tunnel walls in comparison with the general track; in the frequency domain, the vibration effect is gradually increased with frequency increase and reaches the optimal effect in medium-high frequency. The maximum vibration attenuation quantity of frequency division reaches up to 40 dB; and the maximum Z weighted vibration acceleration level is reduced by 22 dB.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 388-392
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.388
• Online since: December 2014
• Authors: Heng Zhang, Miao Miao Huo, Lei Meng, Xiao Shi An
• Keywords: Metro, Steel Spring Floating Slab Track, Vibration, Vibration Attenuation

References

[1] GROOTENHUIS P. Floating track slab isolation [J]. Journal of Sound and Vibration, 1977, 51(3): 443-448.

DOI: 10.1016/s0022-460x(77)80087-4

[2] LIU Xiaoqiang. Research on the vertical vibration transmissibility of steel spring floating slab track structure on the 32m simply supported box beam [D]Beijing. Beijing Jiaotong University, 2007: 5. (In Chinese).

[3] WANG Wenbin, LIU Weining, JIA Yingxuan, SUN Xiaojing, LI Kefei. Research on the Vibration of the Ground Caused by Metro Train operation before and after Changing the Damping Fasteners [J]. China Railway science, 2010, 31(1): 81. (In Chinese).

[4] WEI Jincheng, HE Ping, LI Yujie. Analysis on the Vibration Attenuation of Metro Steel Spring Floating Slab Track [J]. China Railway science, 2012, 33(8): 19-23. (In Chinese).
