Research on Deformation Influence of Shield Undercrossing the Existing Metro Double Shield Tunnel

Abstract:

In the big cities, the shield undercrossing metro project has become critical to the safety of the metro, this paper takes the South-North Water Transfer Project shield under traverse Beijing certain subway project for construction background. It makes technical schemes comparison, analyses the deformation law of the existing subway structure and propoes protective measures to prevent the existing subway structure. The analysis showed the following conclusions: in shield undercrossing the metro project, in order to reduce disturbance on surrounding soils and the existing metro structure, we should take the necessary control measures such as grouting and determine the optimum shield parameters; the overall trend of the monitoring results accords well with numerical simulation results; The reason why the actual values and model calculation values has certain deviation is that it is difficult to consider shield parameters such as the pressure of shield thrust, pressures of grouting and so on in numerical simulation.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 378-382
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.378
• Online since: December 2014
• Authors: Hua Peng, Zhi Yong Dong, Yun Liang Liu
• Keywords: Control Measures, Deformation, Numerical Simulation, Shield Tunnel, Undercrossing

References

[1] Shi Zhongheng, Zhang Mi. Design and construction of subway [M]. Xi'an: Shanxi Science and Technology Press, (1997).

[2] Tang Xiaowu, ZhuJi, LiuWei. 2010. The Research of Soil Deformation in the process of Shield Construction [J]. Chinese Journal of Rock Mechanic and Engineering, 29(2): 417-422.

[3] GB50157-2003. 2003. Code for Design of Metro[S]. Beijing: Chinese Railway Publishing House.

[4] Guo Qiang. 2010. Research on the Track Deformation and Dynamic Characteristics under the Conditions of Electric Shield Tunnel Undercrossing the Existing Metro Tunnel [D]. Beijing: Beijing Jiaotong University.

[5] Lu Gaofeng, Wei Qingchao. Safety analysis on the bridge traversed by metro double-line tunnels [J]. Journal of Beijing Jiaotong University, 2008, 32(4): 103-107.

[6] Thomas Kasper, Gunther Meschke. On the influence of face pressure, grouting pressure and TBM design in soft ground tunneling [J]. Tunneling and Underground Space Technology, 2006, 21: 160~171.

DOI: 10.1016/j.tust.2005.06.006
